We're professional electrostatic precipitator dust collector manufacturers and suppliers in China, to buy or wholesale electrostatic dust collector from our factory. For quotation or if you have any questions, contact us now for customized esp dust collector and price.
● Efficient dust removal: Electrostatic precipitator can effectively remove particles in the air, including fine dust and smoke.
● Low energy consumption: Compared with the traditional filter, the electrostatic precipitator has lower energy consumption and saves energy.
● Long service life: The core component of electrostatic precipitator is metal collecting plate, which has a long service life and is not easy to wear.
● No need to change the filter element: Compared with the traditional filter, the electrostatic precipitator does not need to change the filter element regularly, which reduces the maintenance cost.
Technical parameter model | JPCWD10×3 | JPCWD12.5×3 | JPCWD15×3 | JPCWD20×3 | JPCWD25×3 | JPCWD30×3 | JPCWD35×3 | JPCWD40×3 | JPCWD45×3 | JPCKD50×3 | JPCKD60×3 | JPCKD70×3 | JPCKD80×3 | JPCKD90×3 | JPCKD100×3 | JPCKD110×3 | JPCKD120×3 | JPCKD130×3 | JPCKD260×3 | JPCKD280×3 | JPCKD300×3 |
Effective sectional area (m2) | 10.2 | 12.8 | 15.1 | 20.2 | 25 | 30 | 35.6 | 40.4 | 45 | 49.9 | 60.8 | 71.4 | 81.1 | 90.6 | 100 | 110.6 | 120.2 | 131.4 | 262.9 | 283.7 | 300.5 |
Handling air volume ×104(m3/h) | 3.24～4.32 | 4.05～5.4 | 4.86～6.48 | 6.48～8.64 | 8.1～10.8 | 10.8～12.96 | 12.6～15.12 | 14.4～17.28 | 16.2～19.44 | 18～21.6 | 21.6～25.9 | 25.2～30.2 | 28.8～34.5 | 32.4～38.8 | 36～43.2 | 39.6～47.5 | 43.2～51.8 | 46.8～56.1 | 93.6～112.3 | 100.8～120.9 | 108～129.6 |
Electric field wind speed (m/s) | 0.9～1.2 | 1～1.2 | 1～1.2 | 1～1.2 | |||||||||||||||||
The dust collector bears negative pressure (Pa) | —6000～0 | —6000～0 | —6000～0 | ||||||||||||||||||
Allowable temperature of gas (℃) | ≤300 | ≤300 | ≤300 | ||||||||||||||||||
Design efficiency (%) | ≥99 | ≥99 | ≥99 | ||||||||||||||||||
Pressure loss (Pa) | ≤300 | ≤300 | ≤300 | ||||||||||||||||||
Air leakage rate (%) | ≤5 | ≤5 | ≤5 | ||||||||||||||||||
Number of electric fields/number of chambers | 3 electric field/single chamber | 3 electric field/single chamber | 3 electric field/double chamber | ||||||||||||||||||
Effective length of electric field (m) | 3.5×3=10.5 | 4.0×3=12(3.5×3=10.5) | 4.0×3=12（3.5×3=10.5） | ||||||||||||||||||
Total effective area of anode plate (m2) | 818（716） | 1028（900） | 1209（1058） | 1622（1420） | 1996（1747） | 2400（2100） | 2850（2494） | 3237（2833） | 3600（3150） | 3992（3492） | 4868（4260） | 5715（5000） | 6493（5681） | 7252（6345） | 8002（7002） | 8847（7741） | 9615（8413） | 10516（9202） | 21033（18404） | 22694（19857） | 24038（21033） |
Anode plate type | C type plate |
| C-plate corrugated plate | ||||||||||||||||||
Anode rapping type | Side vibration of flexible arm hammer | Vibrate the side of the flexible arm hammer. | Side vibration of flexible arm hammer | ||||||||||||||||||
Cathode linear type | Mang thorn line fishbone line | Barb line fishbone line barb line fishbone line sawtooth line | Barb line fishbone line sawtooth line | ||||||||||||||||||
Cathode rapping type | Vibrating at the top of the flexible arm hammer | Vibrate the side of the flexible arm hammer. | Side vibration of flexible arm hammer | ||||||||||||||||||
Number of high-voltage power supplies | 3 sets | Three sets, three sets | 6 sets | ||||||||||||||||||
Parameter output current of high voltage power supply (A) | 0.1 | 0.1 | 0.1 | 0.2 | 0.2 | 0.2～0.3 | 0.2～0.3 | 0.3～0.4 | 0.3～0.4 | 0.4～0.5 | 0.5～0.6 | 0.5～0.7 | 0.6～0.8 | 0.7～0.9 | 0.7～1.0 | 0.8～1.1 | 0.9～1.2 | 1.0～1.4 | 1.1～1.4 | 1.0～1.5 | 1.1～1.6 |
Output voltage (KV) | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 |
Overall dimensions of equipment (length× width× height) (m) | 17.8（16.3）×5.65×10.9 | 17.8（16.3）×5.65×11.7 | 18.4（16.9）×6.05×12.0 | 18.8（17.3）×6.45×13.0 | 18.8（17.3）×7.26×13.6 | 19.7（18.2）×7.26×14.65 | 19.7（18.2）×8.13×15.35 | 20.1（18.6）×8.13×16.2 | 20.1（18.6）×8.53×16.9 | 22.9（21.4）×8.88×17.15 | 22.9（21.4）×9.38×18.45 | 23.9（22.4）×10.58×17.25 | 23.9（22.4）×10.93×18.45 | 23.9（22.4）×11.63×18.85 | 23.9（22.4）×12.43×19.25 | 24.9（23.4）×12.43×20.35 | 24.9（23.4）×12.43×21.35 | 24.9（23.4）×13.33×21.35 | 24.9（23.4）×25.75×21.55 | 24.9（23.4）×29.0×20.85 | 24.9（23.4）×29.0×21.55 |
Equipment reference weight (t) | 60.5（55） | 68（62） | 76（69） | 91（83） | 105（95） | 117（106） | 130（118） | 142（129） | 154（140） | 178（166） | 206（192.5） | 234（219） | 260（243.5） | 284（266） | 310（289.5） | 334（312） | 357（333.5） | 382（356） | 730（680） | 784（732） | 833（777） |
JPAC focuses on providing high-quality electrostatic dust collector and excellent service since 1982. We are a professional electrostatic dust collector manufacturer and factory of 43000M2 which mainly produce central air conditioning units and dust collector products for around 44 years’ experience. JPAC provides you with electrostatic dust collector wholesale, customization, design, packaging, industry solutions and OEM & ODM service.
If you have any questions about electrostatic precipitator dust collector, electrostatic dust collector, esp dust collector, electrostatic dust fall collector, please don't hesitate to contact us at any time. We will provide detailed information and technical support about central air conditioning units and dust collectors’ features, specifications, solutions and customization options... Welcome you to visit our factory!
