We're professional embedded fan coil unit manufacturers and suppliers in China, to buy or wholesale cassette fan coil unit from our factory. For quotation or if you have any questions, contact us now for customized blowing fan coil unit and price.
● Use high-efficiency aluminum fin heat exchange and low-noise fans to strengthen heat exchange and maximize the heat transfer efficiency of the heat exchanger;
● Precise design allows you to order left or right coils at will. If the user needs, an automatic temperature control device can be equipped to perform constant temperature control of the controlled place; (the temperature control device must be ordered separately)
● The motor is an energy-saving fixed-phase split capacitor motor, and the bearings are imported high-precision steel ball bearings that can be automatically lubricated. The motor shafts have been specially treated with tempering and hard chromium, and the fixed parts are easy to disassemble and assemble. The motor lead wires are protected by metal hoses and comply with national standards;
● The static pressure of the ordinary coil outlet is 0-12Pa, and the static pressure of the residual pressure type outlet is 30Pa (or ≤50Pa), code-named H;
● The water tray and thermal insulation are molded, and the finishing and gluing process is strong.There are no weld marks, the appearance is beautiful and light, and there is no condensation or dripping; the surface-mounted coils are made of plates produced by Shanghai Baosteel, and the surface is spray-coated, while the concealed coils are made of galvanized sheets or fingerprint-resistant sheets;
● The coil material is made of seamless red copper tubes strung with corrugated aluminum fins through hydraulic or mechanical expansion. The coil box is pasted with sound-absorbing insulation materials. The copper tubes are staggered and have heat transfer performance and extremely low air resistance.
| model | A | B | C |
| FP-34 | 650 | 590 | 390 |
| FP-51 | 650 | 590 | 390 |
| FP-68 | 800 | 730 | 390 |
| FP-85 | 800 | 730 | 430 |
| FP-102 | 800 | 730 | 430 |
| FP-136 | 950 | 850 | 390 |
| FP-170 | 950 | 850 | 390 |
| FP-204 | 950 | 850 | 390 |
| FP-238 | 1140 | 1040 | 390 |
JPAC focuses on providing high-quality embedded fan coil unit and excellent service since 1982. We are a professional embedded fan coil unit manufacturer and factory of 43000M2 which mainly produce central air conditioning units and dust collector products for around 44 years’ experience. JPAC provides you with embedded fan coil unit wholesale, customization, design, packaging, industry solutions and OEM & ODM service.
If you have any questions about embedded fan coil unit, cassette fan coil unit, blowing fan coil unit, fan coil unit, please don't hesitate to contact us at any time. We will provide detailed information and technical support about central air conditioning units and dust collectors’ features, specifications, solutions and customization options... Welcome you to visit our factory!
