Jiangping water-cooled air-conditioning and combined air handling units are selected for the cogeneration project of Gangqiao Park's 'Big Up and Down Under' cogeneration project

1

Constant temperature and humidity air conditioning unit

Refrigeration capacity: 105kW, heating capacity: 25kW, air volume: 29838 m³/h, total unit power P=____kW/380V, electric heating capacity: 25kW, high-pressure micro-mist humidification, humidification capacity: 0.59g/s

Residual pressure outside the machine: 500Pa.

Equipped with complete control system

个

2

For use in electronic equipment room areas

Roof of centralized control building (one for use and one for backup)

2

Combined air conditioning unit

Refrigeration capacity 85.6kW, heating capacity: 36kW, air volume 14253 m³/h, total unit power P=____kW/380V, electric heating capacity: 36kW

Residual pressure outside the machine: 500Pa.

Equipped with complete control system

个

2

Used for centralized control areas

Roof of centralized control building (one for use and one for backup)

serial number

name

Specification

unit

quantity

Remark

1

Vertical cabinet water-cooled air conditioning unit

1. Model ____, cooling capacity 10KW, air volume 2000m3/h, outlet residual pressure: 250Pa, power ___W/380V

2. The equipment is equipped with an electric three-way regulating valve, PN=1.6MPa (for water pipes)

3. The return air belt is equipped with temperature sensors and other supporting control facilities

4. The equipment is equipped with an outlet air valve, the size of which is the same as the equipment outlet size.

5.With control box

个

2

Main factory building 0m gas turbine power distribution room, waste heat boiler electronic equipment room

2

Vertical cabinet water-cooled air conditioning unit

1. Model ____, cooling capacity 15KW, air volume 3000m3/h, outlet residual pressure: 250Pa, power ___W/380V

2. The equipment is equipped with an electric three-way regulating valve, PN=1.6MPa (for water pipes)

3. The return air belt is equipped with temperature sensors and other supporting control facilities

4. The equipment is equipped with an outlet air valve, the size of which is the same as the equipment outlet size.

5.With control box

个

2

Main factory building 0m gas turbine electronic equipment room

3

Vertical cabinet water-cooled air conditioning unit

1. Model ____, cooling capacity 25KW, air volume 5000m3/h, outlet residual pressure: 250Pa, power ___W/380V

2. The equipment is equipped with an electric three-way regulating valve, PN=1.6MPa (for water pipes)

3. The return air belt is equipped with temperature sensors and other supporting control facilities

4. The equipment is equipped with an outlet air valve, the size of which is the same as the equipment outlet size.

5.With control box

个

2

Main factory building 0m condensate pump inverter room, main factory building 6.5m turbine excitation system equipment room

4

Vertical cabinet water-cooled air conditioning unit

1. Model ____, cooling capacity 40KW, air volume 7000m3/h, outlet residual pressure: 250Pa, power ___W/380V

2. The equipment is equipped with an electric three-way regulating valve, PN=1.6MPa (for water pipes)

3. The return air belt is equipped with temperature sensors and other supporting control facilities

4. The equipment is equipped with an outlet air valve, the size of which is the same as the equipment outlet size.

5.With control box

个

1

Main workshop 6.5m gas turbine excitation system equipment room

5

Vertical cabinet water-cooled air conditioning unit

1. Model ____, cooling capacity 60KW, air volume 9000m3/h, outlet residual pressure: 250Pa, power ___W/380V

2. The equipment is equipped with an electric three-way regulating valve, PN=1.6MPa (for water pipes)

3. The return air belt is equipped with temperature sensors and other supporting control facilities

4. The equipment is equipped with an outlet air valve, the size of which is the same as the equipment outlet size.

5.With control box

个

2

Main factory building 6.5m gas turbine SFC equipment room (used during startup)

6

fan coil unit

1. Model ____, cooling capacity 3600W, air volume 600m3/h, power ___W/220V
2. Built-in air box and air louvers

个

1

Main factory building 6.5m gas turbine SFC equipment room (used during startup)

7

Vertical cabinet water-cooled air conditioning unit

1. Model ____, cooling capacity 20KW, air volume 400m3/h, outlet residual pressure: 250Pa, power ___W/380V

2. The equipment is equipped with an electric three-way regulating valve, PN=1.6MPa (for water pipes)

3. The return air belt is equipped with temperature sensors and other supporting control facilities

4. The equipment is equipped with an outlet air valve, the size of which is the same as the equipment outlet size.

5.With control box

个

2

9m6kV power distribution room in the main factory building (used during operation)

8

Vertical cabinet water-cooled air conditioning unit

1. Model ____, cooling capacity 5KW, air volume 1000m3/h, outlet residual pressure: 250Pa, power ___W/380V

2. The equipment is equipped with an electric three-way regulating valve, PN=1.6MPa (for water pipes)

3. The return air belt is equipped with temperature sensors and other supporting control facilities

4. The equipment is equipped with an outlet air valve, the size of which is the same as the equipment outlet size.

5.With control box

个

1

Waste heat boiler low voltage distribution room

9

Vertical cabinet water-cooled air conditioning unit

1. Model ____, cooling capacity 85KW, air volume 15000m3/h, outlet residual pressure: 250Pa, power ___W/380V

2. The equipment is equipped with an electric three-way regulating valve, PN=1.6MPa (for water pipes)

3. The return air belt is equipped with temperature sensors and other supporting control facilities

4. The equipment is equipped with an outlet air valve, the size of which is the same as the equipment outlet size.

5.With control box

个

3

Waste heat boiler frequency converter room

10

Explosion-proof vertical cabinet water-cooled air conditioner

1. Model ____, cooling capacity 30KW, air volume 6000m3/h, outlet residual pressure: 250Pa, power ___W/380V

2. The equipment is equipped with an electric three-way regulating valve, PN=1.6MPa (for water pipes)

3. The return air belt is equipped with temperature sensors and other supporting control facilities

4. The equipment is equipped with an outlet air valve, the size of which is the same as the equipment outlet size.

5.With control box

个

1

Central control building 0m battery room

11

Vertical cabinet water-cooled air conditioning unit

1. Model ____, cooling capacity 51KW, air volume 8000m3/h, outlet residual pressure: 250Pa, power ___W/380V

2. The equipment is equipped with an electric three-way regulating valve, PN=1.6MPa (for water pipes)

3. The return air belt is equipped with temperature sensors and other supporting control facilities

4. The equipment is equipped with an outlet air valve, the size of which is the same as the equipment outlet size.

5.With control box

个

2

Low-voltage electronic equipment room 0m in the centralized control building

12

Vertical fan coil unit

1. Model ____, cooling capacity 3600W, power P=____KW/220V

个

1

6.5m thermal maintenance room in the centralized control building
