3 characteristics of sintered plate dust collector compared with traditional dust collector

Compared with traditional bag or cartridge dust collectors, sintered plate dust collectors have the following characteristics:

1Material characteristics

The material of the corrugated plastic-sintered filter is a combination of several polymer compounds, which are cast and sintered to form a porous matrix. The gaps are then filled with fluorinated resin and then fixed. If easily conductive substances are added to the polymer compound in advance, an anti-static filter plate can be made. The filter-type dust collector is made of pleated filter material bonded end to end.

2 shape characteristics

The corrugated surface can expand the surface area by 3 to 8 times. Although it is not as large as the cartridge dust collector, the more important thing is that the corrugated surface of the sintered plate dust collector meets the needs of aerodynamics. It can ensure that the dust attached to the filter plate is more conducive to cleaning when the pulse air flow back blows the dust.

3 Structural features

The unique coating of The sintered plate filter element has a rigid structure but does not require a steel frame support because its wavy appearance and the ribs between the internal cavities have enough strength to maintain its shape. The structural characteristics of the sintered filter plate also make it extremely convenient to install, replace and clean the filter plate. The operator can complete the assembly of a filter plate by opening the access doors on both sides outside the dust collector and tightening the only two bolts on the upper part of the filter plate. The cartridge dust collector must be supported by a steel frame.the sintered plate dust collector does not exist tightly on the surface of the filter plate, but penetrates deeper into the pores.
