We're professional direct expansion air handling unit manufacturers and suppliers in China, to buy or wholesale direct expansion air conditioning unit from our factory. For quotation or if you have any questions, contact us now for customized air cooled direct expansion air conditioning unit and price.
● It has adopted patented double frame construction, the unit air leakage rate is only 0.16%;
● It has adopted modular design, every modular is 100mm. It has increased proportionally. It can meet the requirements of the width
and height of the unit under the field conditions;
● The unit internal surface is smooth and flat, it is not easy to dust, and has no secondary pollution, which is suitable for purifying
place;
● The outside plate has adopted color steel plate of high-efficiency anti-corrosive, and the surface covered with film, which canprevent the panel from being scratched during assembly and transportation;
● High-efficiency screw compressor, the most advanced tooth design, high precision machining technology, the volume efficiency is
high;
● It adopted refrigerant system control module with European and American famous brand of ALCO, SPORLAN, DANFOSS, the quality
is stable;
● It has adopted superior and high-efficiency double-inlet centrifugal fan, plus the special vibration-proof structure, which can make the small unit vibration, and low noise;
● It has adopted high quite axial flow fan which is conformed to aerodynamic principle, the operation is quite;
● It has adopted single-chip microcomputer controller,LCD display screen, multi-colored backlight, the multiple running modes areavailable;
● It has the function of automatic defrosting and manual forced defrosting.
JPAC focuses on providing high-quality direct expansion air handling unit and excellent service since 1982. We are a professional direct expansion air handling unit manufacturer and factory of 43000M2 which mainly produce central air conditioning units and dust collector products for around 44 years’ experience. JPAC provides you with direct expansion air handling unit wholesale, customization, design, packaging, industry solutions and OEM & ODM service.
If you have any questions about direct expansion air handling unit, direct expansion air conditioning unit, air cooled direct expansion air conditioning unit, please don't hesitate to contact us at any time. We will provide detailed information and technical support about central air conditioning units and dust collectors’ features, specifications, solutions and customization options... Welcome you to visit our factory!
We're professional direct expansion air handling unit manufacturers and suppliers in China, to buy or wholesale direct expansion air conditioning unit from our factory. For quotation or if you have any questions, contact us now for customized air cooled direct expansion air conditioning unit and price.
● It has adopted patented double frame construction, the unit air leakage rate is only 0.16%;
● It has adopted modular design, every modular is 100mm. It has increased proportionally. It can meet the requirements of the width
and height of the unit under the field conditions;
● The unit internal surface is smooth and flat, it is not easy to dust, and has no secondary pollution, which is suitable for purifying
place;
● The outside plate has adopted color steel plate of high-efficiency anti-corrosive, and the surface covered with film, which canprevent the panel from being scratched during assembly and transportation;
● High-efficiency screw compressor, the most advanced tooth design, high precision machining technology, the volume efficiency is
high;
● It adopted refrigerant system control module with European and American famous brand of ALCO, SPORLAN, DANFOSS, the quality
is stable;
● It has adopted superior and high-efficiency double-inlet centrifugal fan, plus the special vibration-proof structure, which can make the small unit vibration, and low noise;
● It has adopted high quite axial flow fan which is conformed to aerodynamic principle, the operation is quite;
● It has adopted single-chip microcomputer controller,LCD display screen, multi-colored backlight, the multiple running modes areavailable;
● It has the function of automatic defrosting and manual forced defrosting.
JPAC focuses on providing high-quality direct expansion air handling unit and excellent service since 1982. We are a professional direct expansion air handling unit manufacturer and factory of 43000M2 which mainly produce central air conditioning units and dust collector products for around 44 years’ experience. JPAC provides you with direct expansion air handling unit wholesale, customization, design, packaging, industry solutions and OEM & ODM service.
If you have any questions about direct expansion air handling unit, direct expansion air conditioning unit, air cooled direct expansion air conditioning unit, please don't hesitate to contact us at any time. We will provide detailed information and technical support about central air conditioning units and dust collectors’ features, specifications, solutions and customization options... Welcome you to visit our factory!
| model | Indoor machine | JZE | 0909 | 1209 | 1409 | 1511 | 1612 | 1812 | |
| JZS | |||||||||
| JZW | |||||||||
| Compression condensing unitCompression condensing unit | JCW | 1008AX | 1010AX | 1012AX | 2015AX | 2020AX | 2025AX | ||
| Rated refrigerating capacity | kW | 26 | 32 | 38 | 46 | 65 | 75 | ||
| Electrical heating capacity(reference) | kW | 12 | 20 | 22 | 24 | 36 | 36 | ||
| Power | 380V/3N~/50Hz | ||||||||
| 室 Indoor unit Indoor machine | Air volumeAir volume | m³/h | 5000 | 6500 | 8000 | 10000 | 12000 | 15000 | |
| Temperature control rangeTemperature control range | Refrigeration 18-28℃ Refrigeration 18-28℃ | ||||||||
| Overall dimension | Wide | mm | 950 | 1250 | 1550 | 1550 | 1650 | 1850 | |
| High | mm | 1030 | 1030 | 1030 | 1230 | 1330 | 1330 | ||
| Length | mm | Determined according to the module of the specific functional segment configuration (see the functional segment size table for details) Determine the module according to the specific function section configuration Iseo the function section size table for details) | |||||||
| Water-cooled compression condensation section | Compressor type*quantityCompressor type*quantity | . | The vortex type*1 The vortex type*1 | The vortex type*2 The vortex type*2 | |||||
| Input power | kW | 5.7 | 6.4 | 7.3 | 10.5 | 12.5 | 14.7 | ||
| Condenser typeCondenser type | High efficient coaxial casing | High efficient shell and tube type | |||||||
| Water volumeWater volume | m³/h | 5.8 | 6.8 | 7.7 | 9.5 | 13.2 | 15.5 | ||
| Water resistanceWater resistance | kPa | 26 | 28 | 30 | 35 | 36 | 40 | ||
| Outine size | Inlet and outlet pipe diameter | in | RC1-1/2' | RC1-1/2' | RC2° | RC21 | RC1-1/2' | RC1-1/2' | |
| Wide | mm | 950 | 1250 | 1550 | 1550 | 1650 | 1850 | ||
| High | mm | 1030 | 1030 | 1030 | 1230 | 1330 | 1350 | ||
| Length | mm | 900 | 900 | 900 | 900 | 900 | 900 | ||
| refrigerant | Working medium | R22 | |||||||
| Charge volume | kg | 3.0 | 3.8 | 4.6 | 2.8*2 | 4.1*2 | 4.6*2 | ||
| Connecting pipe | Connection typeConnection type | Welding connectionWelding connection | |||||||
| Fluid pipe size | 2mm | 15.88*1 | 15.88*1 | 15.88*1 | 15.88*2 | 15.88*2 | 15.88*2 | ||
| TubeI sizeipesize | 0mm | 28.6*1 | 28.6*1 | 28.6*1 | 22.2*2 | 28.6*2 | 28.6*2 | ||
| model | Indoor machine | JZE | 1914 | 2114 | 2018 | 2121 | 2718 | |
| JZS | ||||||||
| JZW | ||||||||
| Compression condensing unitCompression condensing unit | JCW | 3030AX | 3036AX | 4040AX | 4050AX | 5060AX | ||
| Rated refrigerating capacity | kW | 92 | 112 | 130 | 150 | 188 | ||
| Electrical heating capacity(reference) | kW | 45 | 45 | 60 | 65 | 70 | ||
| Power | 380V/3N~/50Hz | |||||||
| Indoor machine | Air volumeAir volume | m³/h | 17500 | 20000 | 25000 | 30000 | 35000 | |
| Temperature control rangeTemperature control range | Refrigeration 18-28℃ Refrigeration 18-28C | |||||||
| Outtino size | Wide | mm | 1950 | 2150 | 2050 | 2170 | 2770 | |
| High | mm | 1530 | 1530 | 1930 | 2250 | 1950 | ||
| Length | mm | Determined according to the module of the specific functional segment configuration (see the functional segment size table for details) Determine the module according to the specific function section configuration[see the function section size table for details] | ||||||
| Water-cooled compression condensation section | Compressor type*quantityCompressor type*quantity | — | The vortex type*3 The vortex type*3 | The vortex type*4 The vortex type*4 | The vortex type*5 The vortex type*5 | |||
| Input power | kW | 18.1 | 21.9 | 25.7 | 29.3 | 36.7 | ||
| Condenser typeCondenser type | High efficient shell and tube type | |||||||
| Water volumeWater volume | m³/h | 19 | 23.2 | 27 | 31 | 38.7 | ||
| Water resistanceWater resistance | kPa | 40 | 40 | 40 | 45 | 45 | ||
| Overall dimensions | Inlet and outlet pipe diameter | in | RC1-1/2' | RC1-1/2' | RC1-1/2' | RC3' | RC3° | |
| Wide | mm | 1950 | 2150 | 2050 | 2170 | 2770 | ||
| High | mm | 1530 | 1530 | 1930 | 2250 | 1950 | ||
| Length | mm | 900 | 900 | 1200 | 1200 | 1200 | ||
| refrigerant | Working medium | R22 | ||||||
| Charge volume | kg | 4.6*2+2.6*1 | 4.6*3 | 4.6*3+2.6*1 | 4.6*4 | 4.6*5 | ||
| 连 take over | Connection typeConnection type | Welding connectionWelding connection | ||||||
| Fluid pipe size | 0mm | 15.88*2+12.7*1 | 15.88*3 | 15.88*3+12.7*1 | 15.88*4 | 15.88*5 | ||
| model | Indoor machine | JZE | 0909 | 1209 | 1409 | 1511 | 1612 | 1812 | |
| JZS | |||||||||
| JZW | |||||||||
| Compression condensing unitCompression condensing unit | JCW | 1008AX | 1010AX | 1012AX | 2015AX | 2020AX | 2025AX | ||
| Rated refrigerating capacity | kW | 26 | 32 | 38 | 46 | 65 | 75 | ||
| Electrical heating capacity(reference) | kW | 12 | 20 | 22 | 24 | 36 | 36 | ||
| Power | 380V/3N~/50Hz | ||||||||
| 室 Indoor unit Indoor machine | Air volumeAir volume | m³/h | 5000 | 6500 | 8000 | 10000 | 12000 | 15000 | |
| Temperature control rangeTemperature control range | Refrigeration 18-28℃ Refrigeration 18-28℃ | ||||||||
| Overall dimension | Wide | mm | 950 | 1250 | 1550 | 1550 | 1650 | 1850 | |
| High | mm | 1030 | 1030 | 1030 | 1230 | 1330 | 1330 | ||
| Length | mm | Determined according to the module of the specific functional segment configuration (see the functional segment size table for details) Determine the module according to the specific function section configuration Iseo the function section size table for details) | |||||||
| Water-cooled compression condensation section | Compressor type*quantityCompressor type*quantity | . | The vortex type*1 The vortex type*1 | The vortex type*2 The vortex type*2 | |||||
| Input power | kW | 5.7 | 6.4 | 7.3 | 10.5 | 12.5 | 14.7 | ||
| Condenser typeCondenser type | High efficient coaxial casing | High efficient shell and tube type | |||||||
| Water volumeWater volume | m³/h | 5.8 | 6.8 | 7.7 | 9.5 | 13.2 | 15.5 | ||
| Water resistanceWater resistance | kPa | 26 | 28 | 30 | 35 | 36 | 40 | ||
| Outine size | Inlet and outlet pipe diameter | in | RC1-1/2' | RC1-1/2' | RC2° | RC21 | RC1-1/2' | RC1-1/2' | |
| Wide | mm | 950 | 1250 | 1550 | 1550 | 1650 | 1850 | ||
| High | mm | 1030 | 1030 | 1030 | 1230 | 1330 | 1350 | ||
| Length | mm | 900 | 900 | 900 | 900 | 900 | 900 | ||
| refrigerant | Working medium | R22 | |||||||
| Charge volume | kg | 3.0 | 3.8 | 4.6 | 2.8*2 | 4.1*2 | 4.6*2 | ||
| Connecting pipe | Connection typeConnection type | Welding connectionWelding connection | |||||||
| Fluid pipe size | 2mm | 15.88*1 | 15.88*1 | 15.88*1 | 15.88*2 | 15.88*2 | 15.88*2 | ||
| TubeI sizeipesize | 0mm | 28.6*1 | 28.6*1 | 28.6*1 | 22.2*2 | 28.6*2 | 28.6*2 | ||
| model | Indoor machine | JZE | 1914 | 2114 | 2018 | 2121 | 2718 | |
| JZS | ||||||||
| JZW | ||||||||
| Compression condensing unitCompression condensing unit | JCW | 3030AX | 3036AX | 4040AX | 4050AX | 5060AX | ||
| Rated refrigerating capacity | kW | 92 | 112 | 130 | 150 | 188 | ||
| Electrical heating capacity(reference) | kW | 45 | 45 | 60 | 65 | 70 | ||
| Power | 380V/3N~/50Hz | |||||||
| Indoor machine | Air volumeAir volume | m³/h | 17500 | 20000 | 25000 | 30000 | 35000 | |
| Temperature control rangeTemperature control range | Refrigeration 18-28℃ Refrigeration 18-28C | |||||||
| Outtino size | Wide | mm | 1950 | 2150 | 2050 | 2170 | 2770 | |
| High | mm | 1530 | 1530 | 1930 | 2250 | 1950 | ||
| Length | mm | Determined according to the module of the specific functional segment configuration (see the functional segment size table for details) Determine the module according to the specific function section configuration[see the function section size table for details] | ||||||
| Water-cooled compression condensation section | Compressor type*quantityCompressor type*quantity | — | The vortex type*3 The vortex type*3 | The vortex type*4 The vortex type*4 | The vortex type*5 The vortex type*5 | |||
| Input power | kW | 18.1 | 21.9 | 25.7 | 29.3 | 36.7 | ||
| Condenser typeCondenser type | High efficient shell and tube type | |||||||
| Water volumeWater volume | m³/h | 19 | 23.2 | 27 | 31 | 38.7 | ||
| Water resistanceWater resistance | kPa | 40 | 40 | 40 | 45 | 45 | ||
| Overall dimensions | Inlet and outlet pipe diameter | in | RC1-1/2' | RC1-1/2' | RC1-1/2' | RC3' | RC3° | |
| Wide | mm | 1950 | 2150 | 2050 | 2170 | 2770 | ||
| High | mm | 1530 | 1530 | 1930 | 2250 | 1950 | ||
| Length | mm | 900 | 900 | 1200 | 1200 | 1200 | ||
| refrigerant | Working medium | R22 | ||||||
| Charge volume | kg | 4.6*2+2.6*1 | 4.6*3 | 4.6*3+2.6*1 | 4.6*4 | 4.6*5 | ||
| 连 take over | Connection typeConnection type | Welding connectionWelding connection | ||||||
| Fluid pipe size | 0mm | 15.88*2+12.7*1 | 15.88*3 | 15.88*3+12.7*1 | 15.88*4 | 15.88*5 | ||
| model | Indoor machine | JZE | 2821 | 2824 | 3027 | 3427 | 3530 | 4230 | |
| JZS | |||||||||
| JZW | |||||||||
| Compression condensing unitCompression condensing unit | JCW | 1058AX | 1078AX | 1092AX | 1107AX | 1115AX | 1127AX | ||
| Rated refrigerating capacity | kW | 205 | 275 | 325 | 375 | 405 | 445 | ||
| Electrical heating capacity(reference) | kW | 100 | 140 | 160 | 180 | 200 | 220 | ||
| Power | 380V/3N~/50Hz | ||||||||
| Indoor unit | Air volumeAir volume | m³/h | 40000 | 50000 | 60000 | 70000 | 80000 | 90000 | |
| Temperature control rangeTemperature control range | Refrigeration 18-28C Refrigeration 18-28C | ||||||||
| Overall dimensionsOutine 5126 | Wide | mm | 2870 | 2870 | 3100 | 3500 | 3600 | 4300 | |
| High | mm | 2250 | 2250 | 2900 | 2900 | 3200 | 3200 | ||
| Length | mm | Determined according to the module of the specific functional segment configuration (see the functional segment size table for details) Determine the module according to the specific function section configuration isee the function section size table for details) | |||||||
| Water-cooled compression cold abdominal section | Compressor type·quantityCompressor type·quantity | . | Screw type*1 Screw type*1 | ||||||
| Input power | kW | 44 | 58 | 65.8 | 75.9 | 83.1 | 92.4 | ||
| Condenser typeCondenser type | — | ient shell and tube type | |||||||
| Water volumeWater volume | m³/h | 42.8 | 57 | 68 | 78 | 84 | 93 | ||
| Water resistanceWater resistance | kPa | 50 | 50 | 50 | 50 | 55 | 60 | ||
| Overall dimensionsOutine 5/26 | Inlet and outlet pipe diametor | in | 4°FLG | 4°FLG | 4'FLG | 4°FLG | 4°FLG | 5'FLG | |
| Wide | mm | 2870 | 2870 | 3100 | 3500 | 3600 | 4300 | ||
| High | mm | 2250 | 2550 | 2900 | 2900 | 3200 | 3200 | ||
| Length | mm | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | ||
| Preparation | Working medium | R22 | |||||||
| Charge volume | kg | 52 | 70 | 83 | 96 | 105 | 115 | ||
| Connecting pipe | Connection typeConnection type | Welding connectionWelding connection | |||||||
| Fluid pipe size | 0mm | 28.6*1 | 34.9*1 | 34.9*1 | 41.3*1 | 41.3*1 | 41.3*1 | ||
| Air pipe sizeAir pipe size | 0mm | 66.7*1 | 79.4*1 | 79.4°1 | 92.1*1 | 92.1*1 | 92.1*1 | ||
| model | Indoor machine | JZE | 2821 | 2824 | 3027 | 3427 | 3530 | 4230 | |
| JZS | |||||||||
| JZW | |||||||||
| Compression condensing unitCompression condensing unit | JCW | 1058AX | 1078AX | 1092AX | 1107AX | 1115AX | 1127AX | ||
| Rated refrigerating capacity | kW | 205 | 275 | 325 | 375 | 405 | 445 | ||
| Electrical heating capacity(reference) | kW | 100 | 140 | 160 | 180 | 200 | 220 | ||
| Power | 380V/3N~/50Hz | ||||||||
| Indoor unit | Air volumeAir volume | m³/h | 40000 | 50000 | 60000 | 70000 | 80000 | 90000 | |
| Temperature control rangeTemperature control range | Refrigeration 18-28C Refrigeration 18-28C | ||||||||
| Overall dimensionsOutine 5126 | Wide | mm | 2870 | 2870 | 3100 | 3500 | 3600 | 4300 | |
| High | mm | 2250 | 2250 | 2900 | 2900 | 3200 | 3200 | ||
| Length | mm | Determined according to the module of the specific functional segment configuration (see the functional segment size table for details) Determine the module according to the specific function section configuration isee the function section size table for details) | |||||||
| Water-cooled compression cold abdominal section | Compressor type·quantityCompressor type·quantity | . | Screw type*1 Screw type*1 | ||||||
| Input power | kW | 44 | 58 | 65.8 | 75.9 | 83.1 | 92.4 | ||
| Condenser typeCondenser type | — | ient shell and tube type | |||||||
| Water volumeWater volume | m³/h | 42.8 | 57 | 68 | 78 | 84 | 93 | ||
| Water resistanceWater resistance | kPa | 50 | 50 | 50 | 50 | 55 | 60 | ||
| Overall dimensionsOutine 5/26 | Inlet and outlet pipe diametor | in | 4°FLG | 4°FLG | 4'FLG | 4°FLG | 4°FLG | 5'FLG | |
| Wide | mm | 2870 | 2870 | 3100 | 3500 | 3600 | 4300 | ||
| High | mm | 2250 | 2550 | 2900 | 2900 | 3200 | 3200 | ||
| Length | mm | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | ||
| Preparation | Working medium | R22 | |||||||
| Charge volume | kg | 52 | 70 | 83 | 96 | 105 | 115 | ||
| Connecting pipe | Connection typeConnection type | Welding connectionWelding connection | |||||||
| Fluid pipe size | 0mm | 28.6*1 | 34.9*1 | 34.9*1 | 41.3*1 | 41.3*1 | 41.3*1 | ||
| Air pipe sizeAir pipe size | 0mm | 66.7*1 | 79.4*1 | 79.4°1 | 92.1*1 | 92.1*1 | 92.1*1 | ||
| Indoor machine | JZE | 0906 | 0906 | 0908 | 0909 | 1209 | 1409 | |
| JZS | ||||||||
| JZW | ||||||||
| outdoor machine outdoor machine | model model | JSA050B(R)X | JSA060B(R)X | JSA075B(R)X | JSA100B(R)X | JSA125B(R)X | JSA150B(R)X | |
| QuantityQuality | 1 | 1 | 1 | 1 | 1 | |||
| Rated refrigerating capacity | w | 12 | 14 | 19 | 26.5 | 30 | 37 | |
| w | 13 | 16 | 21 | 28 | 34 | 41 | ||
| Power | 380V/3N-50Hz | |||||||
| Air volumeAir volume | m³/h | 2500 | 3000 | 4000 | 5000 | 6500 | 7500 | |
| Temperature control rangeTemperature control range | Refrigeration:22-26℃, Heating:18-22℃Refrigeration:22-26*C.heating:18-22℃ | |||||||
| DimensionsOutine 5/20 | Wide | mm | 950 | 950 | 950 | 950 | 1250 | 1450 |
| High | mm | 730 | 730 | 930 | 1030 | 1030 | 1030 | |
| Length | mm | |||||||
| Compressor type*quantity Compressor type*quantity | The vortex type*1 The vortex type*2 | The vortex type*2 The vortex type*2 | ||||||
| Refrigeration input powerRefrigerating input power | w | 4.25 | 4.9 | 6.96 | 8.5 | 10.2 | 11.6 | |
| Heating input powerHeating input power | w | 3.85 | 4.55 | 6.4 | 7.8 | 10.0 | 11.2 | |
| Quality(single unit)Quality[single unit] | Kg | 120 | 120 | 223 | 240 | 260 | 325 | |
| Overall dimensions | Wide | mm | 940 | 940 | 1403 | 1403 | 1588 | 1588 |
| High | mm | 400 | 400 | 821 | 821 | 882 | 882 | |
| Long | mm | 1243 | 1243 | 980 | 980 | 1170 | 1170 | |
| Working medium | R22 | |||||||
| Charge volume | Kg | 4.0 | 4.6 | 4.1*2 | 4.5*2 | 5.1*2 | 6.2*2 | |
| Connection typeConnection type | Internal machine welding connection/external machine bell mouth connection | |||||||
| Fluid pipe size | 0mm | 9.52*1 | 9.52*1 | 12.7*2 | 12.7*2 | 12.7*2 | 12.7*2 | |
| Air pipe sizeAir pipe size | 0mm | 19.05*1 | 19.05*1 | 19.05*2 | 19.05*2 | 19.05*2 | 22.2*2 | |
| Indoor machine | JZE | 0906 | 0906 | 0908 | 0909 | 1209 | 1409 | |
| JZS | ||||||||
| JZW | ||||||||
| outdoor machine outdoor machine | model model | JSA050B(R)X | JSA060B(R)X | JSA075B(R)X | JSA100B(R)X | JSA125B(R)X | JSA150B(R)X | |
| QuantityQuality | 1 | 1 | 1 | 1 | 1 | |||
| Rated refrigerating capacity | w | 12 | 14 | 19 | 26.5 | 30 | 37 | |
| w | 13 | 16 | 21 | 28 | 34 | 41 | ||
| Power | 380V/3N-50Hz | |||||||
| Air volumeAir volume | m³/h | 2500 | 3000 | 4000 | 5000 | 6500 | 7500 | |
| Temperature control rangeTemperature control range | Refrigeration:22-26℃, Heating:18-22℃Refrigeration:22-26*C.heating:18-22℃ | |||||||
| DimensionsOutine 5/20 | Wide | mm | 950 | 950 | 950 | 950 | 1250 | 1450 |
| High | mm | 730 | 730 | 930 | 1030 | 1030 | 1030 | |
| Length | mm | |||||||
| Compressor type*quantity Compressor type*quantity | The vortex type*1 The vortex type*2 | The vortex type*2 The vortex type*2 | ||||||
| Refrigeration input powerRefrigerating input power | w | 4.25 | 4.9 | 6.96 | 8.5 | 10.2 | 11.6 | |
| Heating input powerHeating input power | w | 3.85 | 4.55 | 6.4 | 7.8 | 10.0 | 11.2 | |
| Quality(single unit)Quality[single unit] | Kg | 120 | 120 | 223 | 240 | 260 | 325 | |
| Overall dimensions | Wide | mm | 940 | 940 | 1403 | 1403 | 1588 | 1588 |
| High | mm | 400 | 400 | 821 | 821 | 882 | 882 | |
| Long | mm | 1243 | 1243 | 980 | 980 | 1170 | 1170 | |
| Working medium | R22 | |||||||
| Charge volume | Kg | 4.0 | 4.6 | 4.1*2 | 4.5*2 | 5.1*2 | 6.2*2 | |
| Connection typeConnection type | Internal machine welding connection/external machine bell mouth connection | |||||||
| Fluid pipe size | 0mm | 9.52*1 | 9.52*1 | 12.7*2 | 12.7*2 | 12.7*2 | 12.7*2 | |
| Air pipe sizeAir pipe size | 0mm | 19.05*1 | 19.05*1 | 19.05*2 | 19.05*2 | 19.05*2 | 22.2*2 | |
| Model 3 | Indoor machine | JZE | 1511 | 1512 | 1812 | 2114 | 2018 | 2121 | |
| JZS | |||||||||
| JZW | |||||||||
| Outdoor machine | model | JSA200B[R]X | JSA250B(RJX | JSA150B(R)M | JSA200B(RIM | JSA250B[R]M | JSA200B[R]M | ||
| . quantity. | 1 | 1 | 2 | 2 | 2 | 3 | |||
| Rated refrigerating capacity | kW | 50 | 62 | 74 | 102 | 125 | 152 | ||
| Rated heating capacity[heat pump] | kW | 56 | 68 | 82 | 110 | 128 | 160 | ||
| Power | 380V/3N~/50Hz | ||||||||
| Indoor unit | Air volumeAir volume | m³/h | 10000 | 12000 | 15000 | 20000 | 24000 | 30000 | |
| Temperature control rangeTemperature control range | . | generation:22-26C,heating 18-22C | |||||||
| Outline size | Wide | mm | 1550 | 1550 | 1850 | 2150 | 2050 | 2170 | |
| High | mm | 1230 | 1330 | 1330 | 1530 | 1930 | 2250 | ||
| Length | mm | Determined according to the module of the specific functional segment configuration (see the functional segment size table for details) Determine the module according to the specific function section configuration(see the function section size table for details) | |||||||
| Outdoor outdoor machine | Compressor type*quantityCompressor type*quantity | The vortex type*2 The vortex type*2 | |||||||
| Refrigeration input powerRefrigerating input power | kW | 17.6 | 19.8 | 11.6 | 17.6 | 19.8 | 17.6 | ||
| Heating input powerHeating input power | kW | 16.5 | 18.6 | 11.2 | 16.5 | 18.6 | 16.5 | ||
| Quality(single unit) | kg | 492 | 544 | 325 | 492 | 544 | 492 | ||
| Outline size | Wide | mm | 1808 | 1808 | 1558 | 1808 | 1808 | 1808 | |
| High | mm | 1090 | 1090 | 882 | 1090 | 1090 | 1090 | ||
| Length | mm | 1190 | 1190 | 1170 | 1190 | 1190 | 1190 | ||
| refrigerant | Working medium | R22 | |||||||
| Charge volume | kg | 8.0*2 | 9.5*2 | 6.2*4 | 8.0*4 | 9.5*4 | 8.0*6 | ||
| Connecting pipe | Connection typeConnection type | Welding connectionWelding connection | |||||||
| Fluid pipe size | 0mm | 15.88*2 | 15.88*2 | 12.7*4 | 15.88*4 | 15.88*4 | 15.88*6 | ||
| Air pipe sizeAir pipe size | 0mm | 28.6*2 | 28.6*2 | 22.2*4 | 28.6*4 | 28.6*4 | 28.6*6 | ||
| model | Indoor machine | JZE | 2521 | 2121 | 2624 | 2824 | 3027 | 3427 | 3530 | |
| JZS | ||||||||||
| JZW | ||||||||||
| Outdoor machine | model Model | JSA250B(RJX | JCA1050A[R]X | JCA1067A[R]X | JCA1078A[R]X | JCA1093A(R)X | JCA1108A(R)X | JCA1130A[R]X | ||
| quantity Quantity | 3 | 1 | 1 | 1 | 1 | 1 | 1 | |||
| Rated refrigerating capacity | kW | 186 | 176 | 235 | 272 | 325 | 372 | 451 | ||
| Rated heating capacity[heat pump] | kW | 192 | 216 | 273 | 315 | 375 | 430 | 520 | ||
| Power | . | 380V/3N~/50Hz | ||||||||
| Indoormachine indoor unit | Air volumeAir volume | m³/h | 37500 | 30000 | 40000 | 50000 | 60000 | 70000 | 80000 | |
| Temperature control rangeTemperature control range | — | Refrigeration: 22-26℃, heating 18-22℃ Refrigeration: 2 | ||||||||
| Outline size | Wide | mm | 2570 | 2170 | 2670 | 2870 | 3100 | 3500 | 3600 | |
| High | mm | 2250 | 2250 | 2550 | 2550 | 2900 | 2900 | 3200 | ||
| Length | mm | Determined according to the module of the specific functional segment configuration (see the functional segment size table for details) Determine the module according to the specification configuration(see the function section size table for details) | ||||||||
| outdoor unit Outdoor machine | Compressor type*quantityCompressor type*quantity | 。 | The vortex type*2 The vortex type*1 | Semi-closed screw type*1 Semi-closed screw type*1 | ||||||
| Refrigeration input powerRefrigerating input power | kW | 19.8 | 56.4 | 75.3 | 82.8 | 105.7 | 118 | 139.9 | ||
| Heating input powerHeating input power | kw | 18.6 | 54.9 | 68.5 | 75.2 | 97 | 108.2 | 127.5 | ||
| Quality(single unit) | kg | 544 | 2480 | 2650 | 2850 | 3650 | 3740 | 4200 | ||
| Outline size | Wide | mm | 1808 | 2460 | 2460 | 2460 | 3435 | 3520 | 4500 | |
| High | mm | 1090 | 2235 | 2235 | 2235 | 2235 | 2235 | 2235 | ||
| Length | mm | 1190 | 2400 | 2400 | 2400 | 2400 | 2600 | 2760 | ||
| Secondary refrigerant | Working medium | R22 | ||||||||
| Charge volume | kg | 9.5*6 | 58 | 70 | 76 | 95 | 107 | 130 | ||
| Connecting pipe | Connection typeConnection type | Welding connectionWelding connection | ||||||||
| Fluid pipe size | 0mm | 15.88*6 | 34.9 | 34.9 | 34.9 | 34.9 | 34.9 | 41.3 | ||
| Air pipe sizeAir pipe size | 0mm | 28.6*6 | 66.68 | 66.68 | 79.4 | 79.4 | 79.4 | 79.4 | ||
| Model 3 | Indoor machine | JZE | 1511 | 1512 | 1812 | 2114 | 2018 | 2121 | |
| JZS | |||||||||
| JZW | |||||||||
| Outdoor machine | model | JSA200B[R]X | JSA250B(RJX | JSA150B(R)M | JSA200B(RIM | JSA250B[R]M | JSA200B[R]M | ||
| . quantity. | 1 | 1 | 2 | 2 | 2 | 3 | |||
| Rated refrigerating capacity | kW | 50 | 62 | 74 | 102 | 125 | 152 | ||
| Rated heating capacity[heat pump] | kW | 56 | 68 | 82 | 110 | 128 | 160 | ||
| Power | 380V/3N~/50Hz | ||||||||
| Indoor unit | Air volumeAir volume | m³/h | 10000 | 12000 | 15000 | 20000 | 24000 | 30000 | |
| Temperature control rangeTemperature control range | . | generation:22-26C,heating 18-22C | |||||||
| Outline size | Wide | mm | 1550 | 1550 | 1850 | 2150 | 2050 | 2170 | |
| High | mm | 1230 | 1330 | 1330 | 1530 | 1930 | 2250 | ||
| Length | mm | Determined according to the module of the specific functional segment configuration (see the functional segment size table for details) Determine the module according to the specific function section configuration(see the function section size table for details) | |||||||
| Outdoor outdoor machine | Compressor type*quantityCompressor type*quantity | The vortex type*2 The vortex type*2 | |||||||
| Refrigeration input powerRefrigerating input power | kW | 17.6 | 19.8 | 11.6 | 17.6 | 19.8 | 17.6 | ||
| Heating input powerHeating input power | kW | 16.5 | 18.6 | 11.2 | 16.5 | 18.6 | 16.5 | ||
| Quality(single unit) | kg | 492 | 544 | 325 | 492 | 544 | 492 | ||
| Outline size | Wide | mm | 1808 | 1808 | 1558 | 1808 | 1808 | 1808 | |
| High | mm | 1090 | 1090 | 882 | 1090 | 1090 | 1090 | ||
| Length | mm | 1190 | 1190 | 1170 | 1190 | 1190 | 1190 | ||
| refrigerant | Working medium | R22 | |||||||
| Charge volume | kg | 8.0*2 | 9.5*2 | 6.2*4 | 8.0*4 | 9.5*4 | 8.0*6 | ||
| Connecting pipe | Connection typeConnection type | Welding connectionWelding connection | |||||||
| Fluid pipe size | 0mm | 15.88*2 | 15.88*2 | 12.7*4 | 15.88*4 | 15.88*4 | 15.88*6 | ||
| Air pipe sizeAir pipe size | 0mm | 28.6*2 | 28.6*2 | 22.2*4 | 28.6*4 | 28.6*4 | 28.6*6 | ||
| model | Indoor machine | JZE | 2521 | 2121 | 2624 | 2824 | 3027 | 3427 | 3530 | |
| JZS | ||||||||||
| JZW | ||||||||||
| Outdoor machine | model Model | JSA250B(RJX | JCA1050A[R]X | JCA1067A[R]X | JCA1078A[R]X | JCA1093A(R)X | JCA1108A(R)X | JCA1130A[R]X | ||
| quantity Quantity | 3 | 1 | 1 | 1 | 1 | 1 | 1 | |||
| Rated refrigerating capacity | kW | 186 | 176 | 235 | 272 | 325 | 372 | 451 | ||
| Rated heating capacity[heat pump] | kW | 192 | 216 | 273 | 315 | 375 | 430 | 520 | ||
| Power | . | 380V/3N~/50Hz | ||||||||
| Indoormachine indoor unit | Air volumeAir volume | m³/h | 37500 | 30000 | 40000 | 50000 | 60000 | 70000 | 80000 | |
| Temperature control rangeTemperature control range | — | Refrigeration: 22-26℃, heating 18-22℃ Refrigeration: 2 | ||||||||
| Outline size | Wide | mm | 2570 | 2170 | 2670 | 2870 | 3100 | 3500 | 3600 | |
| High | mm | 2250 | 2250 | 2550 | 2550 | 2900 | 2900 | 3200 | ||
| Length | mm | Determined according to the module of the specific functional segment configuration (see the functional segment size table for details) Determine the module according to the specification configuration(see the function section size table for details) | ||||||||
| outdoor unit Outdoor machine | Compressor type*quantityCompressor type*quantity | 。 | The vortex type*2 The vortex type*1 | Semi-closed screw type*1 Semi-closed screw type*1 | ||||||
| Refrigeration input powerRefrigerating input power | kW | 19.8 | 56.4 | 75.3 | 82.8 | 105.7 | 118 | 139.9 | ||
| Heating input powerHeating input power | kw | 18.6 | 54.9 | 68.5 | 75.2 | 97 | 108.2 | 127.5 | ||
| Quality(single unit) | kg | 544 | 2480 | 2650 | 2850 | 3650 | 3740 | 4200 | ||
| Outline size | Wide | mm | 1808 | 2460 | 2460 | 2460 | 3435 | 3520 | 4500 | |
| High | mm | 1090 | 2235 | 2235 | 2235 | 2235 | 2235 | 2235 | ||
| Length | mm | 1190 | 2400 | 2400 | 2400 | 2400 | 2600 | 2760 | ||
| Secondary refrigerant | Working medium | R22 | ||||||||
| Charge volume | kg | 9.5*6 | 58 | 70 | 76 | 95 | 107 | 130 | ||
| Connecting pipe | Connection typeConnection type | Welding connectionWelding connection | ||||||||
| Fluid pipe size | 0mm | 15.88*6 | 34.9 | 34.9 | 34.9 | 34.9 | 34.9 | 41.3 | ||
| Air pipe sizeAir pipe size | 0mm | 28.6*6 | 66.68 | 66.68 | 79.4 | 79.4 | 79.4 | 79.4 | ||
