We're professional venturi wet scrubber manufacturers and suppliers in China, to buy or wholesale venturi wet dust collector from our factory. For quotation or if you have any questions, contact us now for customized venturi wet collector and price.
● Dust removal efficiency: greater than 99%;
● The indoor purification index and evacuation index are higher than the requirements of national standards, and the dust concentration of the evacuated airflow is < 120 mg/m; Indoor air dust content (without other pollution sources)-80 mg/m;
● Reliable performance, stable operation and no secondary pollution;
● Long service life, little maintenance or even no maintenance;
● Sewage discharge mode: continuous direct discharge;
● reducing the loss of fuel (materials);
● Low energy consumption: the power is between 5.5 kW and 18.5 kW;
● Control mode: local startup or PLC interlocking control.
● Water-gas ratio of dust collector: 200 g/m (0.2 ll/m)
JPCWS series coaxial Venturi water film dust collector is suitable for dust removal at belt transfer point, raw coal bunker, coal drop point of impeller coal feeder, coal plough of coal plough, dust removal at the top of coal drop port and dust removal at material delivery system of other industries in coal-fired power plants. Special equipment for explosive dust.
performance | JPC/WS-8 | JPC/WS -10 | JPC/WS -12 | JPC/WS -14 | JPC/WS -16 | |
Air volume m3/a | 4000~7500 | 8000~10000 | 15000~20000 | 22000~27000 | 32000~38000 | |
Resistance Pa | ＜1200 | ＜1200 | ＜1200 | ＜1200 | ＜1200 | |
spurt mouth | Hydraulic pressure Pa | 9.8×104~14.7×104 | ||||
Water quantity m3/h | 0.6 | 0.8~1.0 | 1.5~2.0 | 2.0~2.7 | 3.2~3.8 | |
Cyclone drum | Hydraulic pressure Pa | 1.96×104 | ||||
Water quantity m3/h | 0.4 | 0.64~0.8 | 1.2~1.6 | 1.76~2.16 | 2.56~3.0 | |
water seal/closing | Hydraulic pressure Pa | 9.8×104 | ||||
Water quantity m3/h | 0.2 | 0.4 | 0.4 | 0.4 | 0.4 | |
C6~48 centrifugal fan | model | 4-79-4A | 4-79-4.5A | 4-79-7C | 4-79-7C | 4-79-8C |
Air volume m3/h | 4000~7500 | 6640~12920 | 15000~21600 | 22000~27000 | 32000~38000 | |
Wind pressure Pa | 2014~1320 | 2696~1618 | 2050~1750 | 2000~1700 | 2050~1850 | |
Revolutions per minute | 2900 | 2900 | 1600 | 1800 | 1600 | |
Motor model | Y132s1-2 | Y160M1-2 | Y180M-4 | Y180L-4 | Y200L-4 | |
Motor power KW | 5.5 | 11.0 | 18.5 | 22.0 | 30.0 | |
Fan weight Kg | 62 | 117 | 420 | 420 | 510 | |
Motor weight Kg | fifty-six | 102 | 162 | one hundred and eighty | 234 | |
Dust collector self-weight Kg | 1200 | 1400 | 2000 | 2400 | 3000 | |
Support weight Kg | 23 | 35 | 150 | 165 | 200 | |
Common weight Kg | 1341 | 1654 | 2852 | 3165 | 3944 | |
JPAC focuses on providing high-quality venturi wet dust collector and excellent service since 1982. We are a professional venturi wet dust collector manufacturer and factory of 43000M2 which mainly produce central air conditioning units and dust collector products for around 44 years’ experience. JPAC provides you with venturi wet dust collector wholesale, customization, design, packaging, industry solutions and OEM & ODM service.
If you have any questions about venturi wet dust collector, venturi wet collector, wet venturi collector, please don't hesitate to contact us at any time. We will provide detailed information and technical support about central air conditioning units and dust collectors’ features, specifications, solutions and customization options... Welcome you to visit our factory!
