Air Cooled Heat Pump Unit

Air cooled heat pump unit is also called high efficiency air cooled heat pump unit or screw air cooled heat pump unit.

● Dedicated high-efficiency screw compressor, advanced tooth design, high-precision processing technology, and high volumetric efficiency.
● The advanced economizer quasi-two-stage compression cycle technology greatly improves the unit's capacity and energy efficiency.
● Advanced Siemens PLC microcomputer controller.

Availability:

Quantity:



Inquire Add to Basket

Product Description

We're professional air cooled heat pump unit manufacturers and suppliers in China, to buy or wholesale high efficiency air cooled heat pump unit from our factory. For quotation or if you have any questions, contact us now for customized screw air cooled heat pump unit and price.

Product features of air cooled heat pump unit

● Dedicated efficient screw compressor, the most advanced tooth design, high precision process-ing, high efficient volume;

● Advanced economizer quasi two stage compression cycle technique can promote the unit capacity and energy efficiency greatly;

● The patented design heat pump energy updater can improve uniformity of coil distribution, and improve unit heating performance of heat exchanger efficiency;

● The pipeline are supported by plastic clamps and other soft support methods, in order to reduce vibration;

It adopts double shell, the cushion is the standard configuration of bottom. The operation is smooth, reliable, and little noise;

● The advanced Siemens PLC microcomputer controller.

Technical parameters of air cooled heat pump unit

Model JCA-B(R)[H][C]			1067	1078	1087	1093	1108	1130	1142	1153	1170	1185	2201	2216	2238	2260	2284
Refrigerating capacity		KW	235.9	270.5	308.3	340.5	373.0	450.0	498.6	531.2	602.4	641.0	713.5	746.0	823.0	900.0	997.2
Heating capacity		KW	264.2	303.0	345.3	381.4	417.8	504.0	558.4	594.9	674.7	717.9	799.1	835.5	921.8	1008.0	1116.9
Partial heat recovery		KW	60.2	69.0	78.6	86.8	95.1	114.8	127.1	135.5	153.6	163.5	181.9	190.2	209.9	229.5	254.3
electrical oxygen	Power		380V/3N~/50Hz
	Rated power input	KW	73.5	85.7	95.1	106.1	117.8	140.1	157.1	164.6	187.3	202.1	223.9	235.6	257.9	280.2	314.2
	Rated operating current	A	131.4	153.2	170.0	191.8	210.6	253.5	280.8	294.2	334.8	361.3	402.4	421.1	464.1	506.9	561.6
Compressor	Type		5-6 asymmetric tooth profite semi-enclosed screw compressor
	Quantity	Platform	1	1	1	1	1	1	1	1	1	1	2	2	2	2	2
	Starting type		Y-△
	Capacity regulator		25%~100%										12.5%~100%
	Input power	KW	66.3	76.9	84.3	95.3	104.6	125.7	142.7	146.6	169.3	180.1	199.9	209.2	230.3	251.4	285.4
	Type		Waterproof and weather resistance, low noise, high effic
	Quantity	Platform	4	4	6	6	6	8	8	10	10	10	12	12	14	16	16
	Total motor power	KW	7.2	8.8	10.8	10.8	13.2	14.4	14.4	18.0	18.0	22.0	24	26.4	27.6	28.8	28.8
Air conditioning water side heat exchanger	Type		Tubular high efficiency heat exchanger
	Water discharge	m³/h	40.6	46.5	53.0	58.6	64.2	77.4	85.8	91.4	103.6	110.3	122.7	128.3	141.6	154.8	171.5
	Water pressure drop	kPa	70	70	70	70	70	70	70	70	70	70	70	70	70	70	70
	Nozzie diameter	DN	80FLG	80FLG	100FLG	100FLO	100FLG	125FLG	125FLG	125FLG	150FLG	150FLG	100FL0×2 set	100FL0×2 set	125FL0+100FL0	0125FL0×2 set	125FL0×2 group
	Water working pressure	MPa	1.6
Partial heat recovery device	Type		Tubular high efficiency heat exchanger
	Water discharge	m³/h	10.3	11.9	13.5	14.9	16.4	19.7	21.9	23.3	26.4	28.1	31.3	32.7	36.1	39.5	43.7
	Water pressure drop	kPa	45	45	45	45	45	45	45	45	45	45	45	45	45	45	45
	Connection pipe diameter	DN	50FLG	50FLG	50FLG	50FLG	65FLG	65FLG	65FLG	65FLG	65FLG	65FLG	65FL3×2 set	65FL3×2 set	65FL3×2 set	65FL3×2 set	65FL0×2 group
	Water side working pressure	MPa	1.6
shape	Length	mm	2550	2550	3520	3520	3520	4500	4500	5500	5500	5500	7120	7120	8100	9080	9080
	Wide	mm	2235	2235	2235	2235	2235	2235	2235	2235	2235	2235	2235	2235	2235	2235	2235
	High	mm	2600	2600	2600	2600	2600	2750	2750	2750	2750	2750	2600	2600	2750	2750	2750
Partial heat recovery period	Variety		R22
Partial heat recovery period	Charge quantity	kg	69	76	85	95	107	120	130	150	165	170	202.2	214	227	240	260
Operating weight		kq	3050	3350	4100	4200	4300	4800	5100	5400	5800	6100	8500	8600	9100	9600	10200

Model JCA-B(R)(H)(C)			2295	2306	2323	2340	2355	2370	3390	3402	3426	3437	3459	3476	3493	3510
Refrigerating capacity		KW	1029.8	1062.4	1133.6	1204.8	1243.4	1282.0	1350.0	1398.6	1495.8	1528.4	1593.6	1664.8	1736.0	1800.0
Heating capacity		KW	1153.4	1189.9	1269.6	1394.4	1392.6	1435.8	1512.0	1566.4	1675.3	1711.8	1784.8	1864.6	1944.3	2024.1
Partial heat recovery		KW	262.6	270.9	289.1	307.2	317.1	326.9	344.3	356.6	381.4	389.7	406.4	424.5	442.7	460.8
Electrical properties	Power		380V/3N~/50Hz
	Rated power input	KW	321.7	329.2	351.9	374.6	389.4	404.2	420.3	437.3	471.3	478.8	493.8	516.5	539.2	561.9
	Rated operating current	A	575.0	588.4	629.0	669.6	696.1	722.5	760.4	787.8	842.4	855.9	882.7	923.2	963.8	1004.4
Compressor	Type		5-6 asymmetric tooth profile semi-enclosed screw compressor
	Quantity	Platform	2	2	2	2	2	2	3	3	3	3	3	3	3	3
	Starting type		Y-△
	Capacity regulator		12.5%~100%						8.3%~100%
	Input power	KW	289.3	293.2	315.9	338.6	349.4	3602	377.1	394.1	428.1	432	439.8	462.5	485.2	507.9
Axial fan	Type				Waterproof and weather-resistant, low noise,				High efficiency axial flow fan Waterproof and weather resistance,low noise
	Quantity	Platform	18	20	20	20	20	20	24	24	24	26	30	30	30	30
	Total motor power	KW	32.4	36.0	36.0	36.0	40.0	44.0	43.2	43.2	43.2	46.8	54.0	54.0	54.0	54.0
Air conditioning water side heat exchanger	Type		Tubular high efficiency heat exchanger
	Water discharge	m³/h	177.1	182.7	195.0	207.2	213.9	220.5	2323	240.6	257.3	262.9	274.1	286.3	298.6	309.6
	Water pressure drop	kPa	70	70	70	70	70	70	70	70	70	70	70	70	70	70
	Nozzle diameter	DN	125FL3×2 set	125FL0×2 group	150FL0×2 set	150FL0×2 set	150FL0×2 set	125FL0×2 group	125FL0×3 group	125FL0×3 group	125FL0×3 group	125FL0×3 group	125FL0×3 group	150FL0×3 set	150FL0×3 set	150FL0×3 set
	Water working pressure	MPa	1.6
Partial heat recovery device	Type		Tubular high efficiency heat exchanger
	Water discharge	m³/h	45.2	46.6	49.7	52.8	54.5	56.2	59.2	61.3	65.6	67	69.9	73	76.1	79.3
	Water pressure drop	kPa	45	45	45	45	45	45	45	45	45	45	45	45	45	45
	Connection pipe diameter	DN	65FL0×2 group	65FLG×2 sets	65FL0×2 group	65FL0×2 group	65FL0×2 group	65FLG×2 sets	65FL0×3 group	65FL0×3 group	65FL0×3 group	65FLG×3 sets	45FL0×3 group	65FL0×3 group	65FLG×3 sets	65FL0×3 group
	Water side working pressure	MPa	1.6
Shape	Length	mm	10080	11080	11080	11080	11080	11080	13660	13660	13660	14660	16660	16660	16660	16660
	Wide	mm	2235	2235	2235	2235	2235	2235	2235	2235	2235	2235	2235	2235	2235	2235
	High	mm	2750	2750	2750	2750	2750	2750	2750	2750	2750	2750	2750	2750	2750	2750
Refrigerant	Variety		R22
Refrigerant	Charge volume	kg	280	300	315	330	335	340	360	370	390	410	450	465	480	495
Operating weight		kg	10500	10800	11200	11600	11900	12200	14400	14700	15300	15600	16200	16600	17000	17400
