We're professional low temperature air source heat pump unit manufacturers and suppliers in China, to buy or wholesale air source heat pump unit from our factory. For quotation or if you have any questions, contact us now for customized air source heat pump system and price.
● It adopts high efficiency compressor with grain wheel air supply and enthalpy increasing. Ita has thefeatures of flexible vortex, world famous and reliable quality;
● A series of technologies, such as jet enthalpy enhancement, over height and super cooling, heat transfer enhancement, intelligent defrost are adopted to optimize the low temperature refrigeration perfor-mance, which will make the unit heating range greatly extend to the lowest in - 25℃;
● The unit can be combined with the same type of module as required, the energy application range islarge;
● The heating energy efficiency under external gas environment of-10℃can reach to 2.7, which hasimproved 20% than regular block heat pump units. Heating energy efficiency under external gas environment of-20℃ can still reach to 2.1.
| Project Parameter Model Type | JMSD-A[R][3][G] | |||||||||||||
| 015-01 | 030-02 | 045-03 | 060-04 | 075-05 | 090-06 | 105-07 | 120-08 | 135-09 | 150-0A | 165-0B | 180-0C | |||
| Module number | pieces | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | |
| W41 A-12 | Heating capacity | KW | 42 | 84 | 126 | 168 | 210 | 252 | 294 | 336 | 378 | 420 | 462 | 504 |
| Input power | KW | 16.5 | 33 | 49.5 | 66 | 82.5 | 99 | 115.5 | 132 | 148.5 | 165 | 181.5 | 198 | |
| W45 A7 | Heating capacity | KW | 63.5 | 127 | 190.5 | 254 | 317.5 | 381 | 444.5 | 508 | 571.5 | 635 | 698.5 | 762 |
| Input power | KW | 19 | 38 | 57 | 76 | 95 | 114 | 133 | 152 | 171 | 190 | 209 | 228 | |
| W7 A35 | Refrigerating capacity | KW | 53 | 106 | 159 | 212 | 265 | 318 | 371 | 424 | 477 | 530 | 583 | 636 |
| Input power | KW | 15.8 | 31.6 | 47.4 | 63.2 | 79 | 94.8 | 110.6 | 126.4 | 142.2 | 158 | 173.8 | 189.6 | |
| Power Supply | 3-380V/3N~/50Hz | |||||||||||||
| Compressor | Type | Fully enclosed scroll compressor | ||||||||||||
| Quantity | Platform | 2 | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 18 | 20 | 22 | 24 | |
| Wind side heat exchanger | Internal thread heat exchange tube, hydrophilic aluminum foil fin type | |||||||||||||
| Axial flow fan | Type | Waterproof and weather resistance, low noise, high efficiency aerofoil fan | ||||||||||||
| Quantity | Platform | 2 | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 18 | 20 | 22.5 | 24 | |
| Total power input | KW | 1.5 | 3 | 4.5 | 6 | 7.5 | 9 | 10.5 | 12 | 13.5 | 15 | 16.5 | 18 | |
| Hot water speaks hot air | Type | Shell and tube high efficiency heat exchanger | ||||||||||||
| Water discharge | m³/h | 9.1 | 18.2 | 27.3 | 36.5 | 45.6 | 54.7 | 63.8 | 72.9 | 82 | 91.1 | 100.3 | 109.2 | |
| Water pressure drop | kPa | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | |
| Connection pipe diameterflange joint | DN50*1 group | DN50*2 group | DN50*3 group | DN50*4 group | DN50*5 group | DN50*6 group | DN50*7 group | DN50*8 group | DN50*9 group | DN50*10 group | DN50*11 group | DN50*12 group | ||
| Water side working pressure | MPa | 1.0 | ||||||||||||
| Recommended diameter of main pipe. | DN50 | DN65 | DN80 | DN100 | DN100 | DN100 | DN125 | DN125 | DN125 | DN125 | DN150 | DN150 | ||
| Shape | Length | mm | 1080 | 2510 | 3940 | 5370 | 6800 | 8230 | 9660 | 11090 | 12520 | 13950 | 15380 | 16810 |
| Wide | mm | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | |
| High | mm | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | |
| Operating weight | kg | 750 | 1500 | 2250 | 3000 | 3750 | 4500 | 5250 | 6000 | 6750 | 7500 | 8250 | 9000 | |
| ProjectTeam ParameterModelType | JMSD-A(R)(3)(G) | |||||||||||||
| 020-01 | 040-02 | 060-03 | 080-04 | 100-05 | 120-06 | 140-07 | 160-08 | 180-09 | 200-0A | 220-08 | 240-00 | |||
| Module number | Dividual | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | |
| W41 A-12 | Heating capacity | KW | 47 | 94 | 141 | 188 | 235 | 282 | 329 | 376 | 423 | 470 | 517 | 564 |
| Input power | KW | 18 | 36 | 54 | 72 | 90 | 108 | 126 | 144 | 162 | 180 | 198 | 216 | |
| W45A7 | Heating capacity | KW | 71 | 142 | 213 | 284 | 355 | 426 | 497 | 568 | 639 | 710 | 781 | 852 |
| Input power | KW | 20.5 | 41 | 61.5 | 82 | 102.5 | 123 | 143.5 | 164 | 184.5 | 205 | 225.5 | 246 | |
| W7 A35 | Refrigerating capacity | KW | 67 | 134 | 201 | 268 | 335 | 402 | 469 | 536 | 603 | 670 | 737 | 804 |
| Input power | KW | 20 | 40 | 60 | 80 | 100 | 120 | 140 | 160 | 180 | 200 | 220 | 240 | |
| Power Supply | 3-380V/3N~/50Hz | |||||||||||||
| compressor | Type | Fully enclosed scroll compressor | ||||||||||||
| Quantity | Platform | 2 | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 18 | 20 | 22 | 24 | |
| Wind side heat exchanger | Internal thread heat exchange tube,hydrophilic aluminum foit fin type | |||||||||||||
| Axial flow fan | TypeType | Waterproof and weather resistance, low noise, high efficiency aerofoil fan | ||||||||||||
| Quantity | Platform | 2 | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 18 | 20 | 22 | 24 | |
| Total power input | KW | 1.5 | 3 | 4.5 | 6 | 7.5 | 9 | 10.5 | 12 | 13.5 | 15 | 16.5 | 18 | |
| Hot water side heat exchanger | Type | Shell and tube high efficiency heat exchanger | ||||||||||||
| Water discharge | m³/h | 11.5 | 23 | 34.6 | 46.1 | 57.6 | 69.1 | 80.7 | 92.2 | 103.7 | 115.2 | 126.7 | 138.3 | |
| Water pressure drop | kPa | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | |
| Connection pipe diameter/'lange joint | DN50*1 group | DN50*2 group | DN50*3 group | DN50*4 group | DN50*5 group | DN50*6 group | DN50*7 group | DN50*8 group | DN50*9 group | DN50*10 group | DN50*11 group | DN50*12 group | ||
| Water side working pressure | MPa | 1.0 | ||||||||||||
| Recommended diameter of main pipe | DN50 | DN65 | DN80 | DN100 | DN100 | DN125 | DN125 | DN125 | DN150 | DN150 | DN150 | DN150 | ||
| Shape | Length | mm | 1080 | 2510 | 3940 | 5370 | 6800 | 8230 | 9660 | 11090 | 12520 | 13950 | 15380 | 16810 |
| Wide | mm | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | 2155 | |
| High | mm | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | |
| Operating weight | kg | 800 | 1600 | 2400 | 3200 | 4000 | 4800 | 5600 | 6400 | 7200 | 8000 | 8800 | 9600 | |
| ProjectTeam ParameterModelType | JMSD-A(R)[3)[G) | |||||||
| 040-01 | 080-02 | 120-03 | 160-04 | 200-05 | 240-06 | |||
| Module number | Dividual | 1 | 2 | 3 | 4 | 5 | 6 | |
| W41 A-12 | Heating capacity | KW | 94 | 188 | 282 | 376 | 470 | 564 |
| Input power | KW | 36 | 72 | 108 | 144 | 180 | 216 | |
| W45 A7 | Heating capacity | KW | 142 | 284 | 426 | 568 | 710 | 852 |
| Input power | KW | 41 | 82 | 123 | 164 | 205 | 246 | |
| W7 A35 | Refrigerating capacity | KW | 134 | 268 | 402 | 536 | 670 | 804 |
| Input power | KW | 40 | 60 | 120 | 160 | 200 | 240 | |
| Power Supply | 3-380V/3N~/50Hz | |||||||
| compressor | Type | Asymmetric Tooth Semi-closed Screw Compressor | ||||||
| Quantity | Platform | 4 | 8 | 12 | 16 | 20 | 24 | |
| Wind side heat exchanger | Internally threaded heat exchange tube, hydrophilic aluminum foil fin type Inside Threaded Copper Tube Short Sheet Type | |||||||
| Axial flowtan | Type | Waterproof, Weatherproof, Low Noise and High Efficiency Axiat | ||||||
| Quantity | Platform | 2 | 4 | 6 | 8 | 10 | 12 | |
| Total power input | KW | 3.6 | 7.2 | 10.8 | 14.4 | 18 | 21.6 | |
| Hot water side heat exchanger | Type | Shell-and-tube heat exchanger with high efficiency | ||||||
| Water discharge | m³/h | 23 | 46.1 | 69.1 | 922 | 115.2 | 138.3 | |
| Water pressure drop | kPa | 45 | 45 | 45 | 45 | 45 | 45 | |
| Connection pipe diameter/liange joint | D65*1 group | DN65*2 group | DN65*3 group | DN65*4 group | DN65*5 group | DN65*6 group | ||
| Water side working pressure | MPa | 1.0 | ||||||
| Recommended diameter of main pipe | DN65 | DN100 | DN125 | DN125 | DN150 | DN150 | ||
| Shape | Length | mm | 1260 | 2870 | 4480 | 6090 | 7700 | 9310 |
| Wide | mm | 2275 | 2275 | 2275 | 2275 | 2275 | 2275 | |
| High | mm | 2310 | 2310 | 2310 | 2310 | 2310 | 2310 | |
| Operating weight | kg | 1250 | 2500 | 3750 | 5000 | 6250 | 7500 | |
JPAC focuses on providing high-quality low temperature air source heat pump unit and excellent service since 1982. We are a professional low temperature air source heat pump unit manufacturer and factory of 43000M2 which mainly produce central air conditioning units and dust collector products for around 44 years’ experience. JPAC provides you with low temperature air source heat pump unit wholesale, customization, design, packaging, industry solutions and OEM & ODM service.
If you have any questions about low temperature air source heat pump unit, air source heat pump unit, air source heat pump system, heat pump ac unit, please don't hesitate to contact us at any time. We will provide detailed information and technical support about central air conditioning units and dust collectors’ features, specifications, solutions and customization options... Welcome you to visit our factory!
