Evaporative Condensing Screw Chiller

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button
Evaporative water chiller is also called evaporative condensing screw chiller or water cooled screw chiller.

● Adopting a new generation of 5:6 screw tooth profile design, high-precision grinding and processing, and high volumetric efficiency.
● It adopts international high-efficiency fluorine-resistant motor, which is at the best efficiency under various operating conditions.
● Strict air tightness and vacuum testing to ensure that the whole machine and components have no leakage points.

Availability:
Quantity:
Inquire Add to Basket

We're professional evaporative water chiller manufacturers and suppliers in China, to buy or wholesale evaporative condensing screw chiller from our factory. For quotation or if you have any questions, contact us  now for customized water cooled screw chiller and price.


Product features of evaporative water chiller

● It has adopted the latest generation 5:6 screw tooth design, high precision grinding, and high volume efficiency;· The high efficiency fluorine resistant motor of international famous brand can make sure the optimum efficiency under various operating conditions;

● Strict air tightness and vacuum test can make sure that the complete machine and components have no leaks;· Evaporative condenser si ell is made of imported aluminum zinc plate, which has strong thermal resistance property, high heat resistance and beautiful appearance;

● Streamlined inlet air duct with small wind resistance, large air volume, low noise, good performance and high efficiency;

● Advanced Siemens PLC microcomputer controller.


Performance parameters of evaporative water chiller

Model JCWF-BZ 1090 1105 1120 1145 1175 1195 1210 1230 1260 1310 1355 1380
Refrigerating capacity KW 316 374 418 509 619 688 747 818 920 1081 1255 1334

Power 380V/3N~/50HZ
Input power KW 60.6 70.6 80.0 97.6 113.4 131.4 136.5 151.2 170 204.1 226.1 245
Running current A 94.6 111.0 124.4 153.2 176.7 194.6 213.8 233.9 265.8 304.4 350.4 372.4
Compressor machine Type Semi-enclosed screw compressor
Quantity Platform 1

1 1 1 1 1 1 1 1 1
Start model Y
Energy regulation 25%~100%
Input power kW 55.5 65.1 73.0 89.9 103.7 114.2 125.5 137.2 156.0 178.6 205.6 218.5
The refrigeration efficiency 5.69 5.74 5.73 5.66 5.97 6.02 5.95 5.96 5.96 6.05 6.11 6.11
Evaporative conderser Type High efficiency evaporative condenser
Model KKS-475 KKS-550 KKS-670 KKS-780 KKS-940 KKS-1050 KKS-1165 KKS-1285 KKS-1420 KKS-1690B KKS-1935 KKS-2010
Quantity 1 1 1 1 1 1 1 1 1 1 1
Fan powerFan power kW 4 4 5.5 5.5 7.5 15 8 11 11 22.5 16.5 22.5
Pump powerPump power kW 1.1 1.5 1.5 2.2 22 2.2 3 3 3 3 4 4
Evaporator TypeType
High efficiency full liquid evaporator
Water flowWater flow m³/h 54.3 64.3 71.9 87.5 106.4 118.3 128.4 140.6 158.2 186.0 215.9 229.4
Water pressure dropWater pressure drop kPa 52 52 52 52 84 93 93 93 93 93 93 93

DN 100 100 100 125 125 125 150 150 150 150 200 200
Lateral water pressure MPa 1.0
Refrigerant R22
Host appearance Length mm 3100 3100 3100 3100 3620 3620 3620 3620 3650 3650 3700 3700
Wide mm 1700 1700 1700 1740 1850 1850 1900 1900 2020 2040 2170 2200
High mm 1900 1900 1900 1940 1980 1980 2040 2040 2120 2220 2360 2460
weight Shipping weight[about] kg 2000 2150 2300 2600 2900 2950 3000 3300 3300 3650 4750 5000
Model JCWF-BZ 1440 1485 2180 2210 2240 2260 2290 2325 2350 2390 2425 2445
Refrigerating capacity KW 1551 1714 633 748 836 923 1017 1143 1237 1375 1496 1564
Electrical properties Power 380V/3N~/50HZ
Input power KW 269.6 300.9 121.2 141.2 160.0 177.6 195.2 210.2 226.8 262.8 273.0 287.7
Running current A 405.8 447.2 189.2 222 248.8 278.8 306.4 252.2 353.4 389.2 427.6 447.7
Compressor Type Semi-enclosed screw compressor
Quantity Platform 1 1 2 2 2 2 2 2 2 2 2 2
Start model Y-△
Energy regulation 25%~100% 12.5%~100%
Input power kW 247.6 272.9 111.0 130.2 146.0 163.6 179.8 190.8 207.4 228.4 251.0 262.7
The refrigeration efficiency 6.26 6.28 5.70 5.74 5.73 5.64 5.66 5.99 5.96 6.02 5.95 5.95
Evaporative condenser Type High efficiency evaporative condenser
Model KPL-2350 KPL-2620 KPL-475 KPL-550 KPL-670 KPL-700 KPL-780 KPL-870 KPL-940 KPL-1050 KPL-1165 KPL-1165
+KPL-1285
Quantity 1 1 2 2 2 2 2 2 2 2 2 1 each
Fan power kw 16.5 22.5 8 8 11 11 11 15 15 30 16 19
Pump power kW 5.5 5.5 2.2 3 3 3 44 4.4 4.4 4.4 6 6
Evaporator  Type
High efficiency full liquid evaporator
Water flow m³/h 266.8 294.8 108.8 128.6 143.8 158.7 175.0 196.6 212.7 236.6 257.0 269.0
Water pressure drop kPa 93 93 72 72 72 72 72 72 72 75 75 80
Connection pipe diameter DN 200 200 125 150 150 150 150 200 200 200 200 200
Lateral water pressure MPa 1.0
Refrigerant R22
Host appearance Length mm 3700 3700 4650 4650 4650 4650 4650 4800 4800 4800 4800 4800
Wide mm 2310 2360 1700 1830 1830 1945 1945 1945 1970 2100 2150 2150
High mm 2800 2950 2050 2130 2130 2205 2205 2205 2240 2320 2385 2385
Weight Shipping weight(about) kg 6200 6300 3400 3700 3900 4300 4600 5200 5350 5950 6050 6100
Operating weight[about] kg 6450 6600 3600 3900 4100 4500 4800 5450 5600 6250 6450 6500
Model JCWF-BZ 2465 2495 2525 2560 2615 2675 2715 2830 2890 2935 2985
Refrigerating capacity KW 1635 1737 1840 1967 2162 2378 2510 2911 3130 3294 3457
Electrical properties Power 380V/3N~/50HZ
Input power KW 302.4 321.2 340.0 367.2 408.2 436.2 452.2 508.9 539.4 570.7 602.0
Running current A 467.8 499.7 531.6 564.4 608.8 664.9 700.8 778.6 812 853.4 894.8
Compressor machine Type Semi-enclosed screw compressor
Quantity Platform 2 2 2 2 2 2 2 2 2 2 2
Start model Y-△
Energy regulation 25%~100% 12.5%~100%
Input power kW 274.4 293.2 312.0 331.2 357.2 390.2 411.2 466.4 495.4 520.7 546.0
The refrigeration efficiency 5.96 5.93 5.90 5.94 6.05 6.09 6.10 6.24 632 633 633
Evaporative condenser Type
High efficiency evaporative condenser
Model KPL-1285
KPL-1420 KPL-1490 KPL-16908
KPL-1935 Take a photo KPL-2350
KPL-2620
Quantity 2 1 each 2 2 2 1 each 2 1 each 2 1 each 2
Fan power kW 22 22 22 30 45 39 33 33 33 39 45
Pump power kw 6 6 6 6 6 7 8 9.5 11 11 11
Evaporator Type
High efficiency full liquid evaporator
Water flow m³/h 281.2 298.8 316.4 338.3 371.9 409.0 431.7 500.7 538.4 566.5 594.6
Water pressure drop kPa 75 75 75 75 75 99 99 113 113 113 113
Connection pipe diameter DN 200 200 200 250 250 250 250 250 250 300 300
Lateral water pressure MPa 1.0
Refrigerant R22
Host appearance Length mm 5000 5000 5000 5000 5050 5500 5500 6000 6000 6000 6000
Wide mm 2150 2250 2250 2250 2280 2370 2370 2465 2520 2570 2570
High mm 2385 2570 2570 2570 2620 2720 2720 2950 2950 3100 3100
weight Shipping weight(about) kg 6200 6800 6900 7000 7100 9400 9700 11000 11200 10650 10800


Evaporative water chiller manufacturer

JPAC focuses on providing high-quality evaporative water chiller and excellent service since 1982. We are a professional evaporative water chiller manufacturer and factory of 43000M2 which mainly produce central air conditioning units and dust collectorproducts for around 44 years' experience. JPAC provides you with evaporative water chiller wholesale, customization, design, packaging, industry solutions and OEM & ODM service.


Where to buy evaporative water chiller?

If you have any questions about evaporative water chiller, evaporative condensing screw chiller, water cooled screw chiller, water cooled screw compressor chiller, screw water chiller, please don't hesitate to contact us at any time. We will provide detailed information and technical support about central air conditioning units and dust collectors’ features, specifications, solutions and customization options... Welcome you to visit our factory!



Previous:
Next:
evaporative water chiller Evaporative condensing screw chiller water cooled screw chiller water cooled screw compressor chiller screw water chiller water screw chiller evaporative cooling ac unit Evaporative screw chiller evaporative condensing water chiller water chiller
Product inquiry

Related Products

Water Cooled Screw Chiller
