We're professional heat recovery screw chiller manufacturers and suppliers in China, to buy or wholesale heat recovery industrial screw chiller from our factory. For quotation or if you have any questions, contact us now for customized heat recovery water chiller and price.
● Energy conservation and environmental protection-the unit will use condensation heat to make domestic hot water during refrigerating, there's no energy consumption and no emission pollution;
● Safe and reliable-no gas or boiler, water and electricity are completely isolated. There was absolutely no dangerous of explosion, poisoning and electric leakage;
● Economy and fashion-make use of waste heat recovery, zero cost of hot water change, enter into conservation-minded society in advance; Low operating cost-the working conditions of the unit can be improved during heat recovery, and it can supply operating efficiency and reduce the operating cos t of the unit;
● Intelligent control-fully automatic microcomputer control, no human monitoring required, which can achieve remote or centralized control, and save management cost.
| JCW Unit Model | Technical parameters of single machine serios | Technical parameters of double machine somes | |||||||||||||||
| 10500 | 1060C | 10700 | 1080C | 1090C | 1100C | 11100 | 11300 | 11400 | 21000 | 21200 | 21400 | 21500 | 21800 | 22000 | 2220C | ||
| Refrigerating capacity | KW | 176 | 200 | 235 | 265 | 310 | 350 | 382 | 430 | 480 | 352 | 400 | 470 | 528 | 420 | 700 | 772 |
| kcal/h | 151360 | 172000 | 202100 | 227900 | 266600 | 301000 | 328520 | 369800 | 412800 | 302720 | 344000 | 404200 | 454080 | 533200 | 602000 | 663920 | |
| Hot recycling | KW | 52 | 56 | 70 | 70 | 86 | 105 | 115 | 120 | 144 | 105 | 112 | 141 | 150 | 170 | 200 | 210 |
| Input power | KW | 388 | 43.5 | 51.4 | 57 | 45 | 73.8 | 822 | 90 | 100.7 | 775 | 87 | 1028 | 114 | 130 | 147.6 | 164 |
| Rated current | A | 45 | 71 | 87 | 96 | 110 | 124 | 138 | 151 | 170 | 130 | 142 | 174 | 192 | 220 | 248 | 276 |
| Energy control range | 25%~100% | 12.5%~100% | |||||||||||||||
| Power type | 380V/3N~/50Hz | 380V/3N~/50Hz | |||||||||||||||
| Type | 5-6asymmetrictooth type semi-closed screw type | ||||||||||||||||
| Starting mode | Y-△ | Y-△ | |||||||||||||||
| Quantity | Platform | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Type | Efficient shell and tube heat exchanger | Efficient shell and tube heat exchanger | |||||||||||||||
| water volume | m³/h | 30 | 34.4 | 40 | 45.6 | 53 | 60 | 66 | 74 | 83 | 61 | 69 | 81 | 91 | 106 | 120 | 131 |
| Pressure drop | kPa | 36 | 48 | 56 | 46 | 46 | 50 | 43 | 52 | 58 | 40 | 50 | 58 | 48 | 46 | 52 | 145 |
| Tubing specification | DN100 | DN100 | DN100 | DN100 | DN125 | DN125 | DN125 | DN150 | DN150 | DN125 | DN125 | DN125 | DN125 | DN150 | DN150 | DN150 | |
| Form | Efficient shell and tube heat exchanger | Efficient shell and tube heat exchanger | |||||||||||||||
| Water volume | m³/h | 38 | 43 | 51 | 57 | 67 | 75 | 82 | 92 | 103 | 76 | 86 | 101 | 114 | 133 | 151 | 164 |
| Pressure drop | kPa | 45 | 46 | 48 | 50 | 50 | 54 | 55 | 55 | 60 | 45 | 42 | 48 | 50 | 50 | 54 | 55 |
| Tubing specification | DN80 | DN80 | DN100 | DN100 | DN100 | DN100 | DN100 | DN125 | DN125 | DN80X2 | DN80X2 | DN100X2 | DN100X2 | DN100X2 | DN100X2 | DN100X2 | |
| Variety | K05 | KGS | |||||||||||||||
| Charge volume | L | 8 | 8 | 14 | 14 | 14 | 14 | 16 | 15 | 18 | 16 | 16 | 28 | 28 | 28 | 28 | 32 |
| Variety | R22 | R22 | |||||||||||||||
| Charge volume | kg | 35 | 35 | 43 | 47 | 55 | 64 | 70 | 76 | 91 | 35X2 | 35X2 | 43X2 | 47X2 | 55X2 | 64X2 | 70X2 |
| Flow control mode | Thermostatic expansion valve | Thermostatic expansion valve | |||||||||||||||
| Form | Plate heat exchanger | Plate heat exchanger | |||||||||||||||
| Water volume | 9 | 10 | 12 | 12 | 15 | 18 | 20 | 20 | 25 | 18 | 19 | 24 | 25 | 29 | 36 | 39 | |
| Pressure drop | 62 | 62 | 62 | 62 | 62 | 62 | 62 | 62 | 62 | 65 | 45 | 45 | 65 | 45 | 45 | 65 | |
| Tubing specification | R2 | R2 | R2 | R2 | R2 | R2 | R2-1/2 | R2-1/2 | R2-1/2 | DN65 | DN65 | DN65 | DN65 | DN65 | DN65 | DN80 | |
| Length | mm | 2800 | 2850 | 2850 | 2850 | 2880 | 2880 | 2880 | 3050 | 3050 | 3200 | 3200 | 3200 | 3200 | 3200 | 3200 | 3400 |
| Wide | mm | 750 | 750 | 800 | 800 | 800 | 800 | 800 | 850 | 850 | 1700 | 1700 | 1700 | 1750 | 1750 | 1750 | 1750 |
| High | mm | 1750 | 1750 | 1800 | 1850 | 1850 | 1850 | 1850 | 2000 | 2050 | 2000 | 2000 | 2000 | 2100 | 2100 | 2100 | 2200 |
| Shipping weight(about) | kg | 1300 | 1300 | 1600 | 2000 | 2100 | 2100 | 2350 | 2500 | 2500 | 3000 | 3200 | 3400 | 4200 | 4200 | 4600 | 5100 |
JPAC focuses on providing high-quality heat recovery screw chiller and excellent service since 1982. We are a professional heat recovery screw chiller manufacturer and factory of 43000M2 which mainly produce central air conditioning units and dust collector products for around 44 years’ experience. JPAC provides you with heat recovery screw chiller wholesale, customization, design, packaging, industry solutions and OEM & ODM service.
If you have any questions about heat recovery screw chiller, heat recovery industrial screw chiller, water cooled screw chiller, water cooled screw compressor chiller, please don't hesitate to contact us at any time. We will provide detailed information and technical support about central air conditioning units and dust collectors' features, specifications, solutions and customization options... Welcome you to visit our factory!
