We're professional jet air handling unit manufacturers and suppliers in China, to buy or wholesale jet air conditioning unit from our factory. For quotation or if you have any questions, contact us now for customized jet air handling unit and price.
● The spherical nozzle with superior performance is used as the air outlet, which does not need the air duct and save space. It is mainly used in the direct air supply system with large space.
● The thermal performance parameters of air conditioning unit is same as ordinary air handling unit, plus check details of P2-P8. The internal sphere courseware of the spherical nozzle of the jet unit can be seen to be adjusted within a certain range, the firing range is far , and the coverage is wide.
● It can widely used to high-space place, like theater, gymnasium, airport, super market, workshop, large commercial building and exhibition hall.
| Mode lJDZ Type | CMH Air volume | Nozale specifications | Nozzle number | Motor power | ||||||||||||||
| Firing range 10m | Firing range 15m | Firing range 20m | Firing range 25m | Firing range 30m | ||||||||||||||
| 4R | 6R | 8R | 4R | 6R | 8R | 4R | 6R | 8R | 4R | 6R | 8R | 4R | 6R | 8R | ||||
| 010 | 1000 | φ315 | 1 | 0.25 | 0.25 | — | 0.25 | 0.18 | — | 0.25 | 0.25 | — | — | — | — | — | — | |
| 015 | 1500 | φ315 | 1 | 0.25 | 0.25 | — | 0.25 | 0.32 | — | 0.32 | 0.37 | — | 0.37 | 0.37 | — | — | — | — |
| 020 | 2000 | φ315 | 1 | 0.32 | 0.45 | — | 0.45 | 0.45 | — | 0.45 | 0.55 | — | 0.55 | 0.55 | — | — | — | — |
| 025 | 2500 | φ315 | 1 | 0.32 | 0.32 | — | 0.32 | 0.55 | — | 0.55 | 0.55 | — | 0.55 | 0.45 | — | 0.45 | 0.45 | — |
| 030 | 3000 | φ315 | 1 | 0.55 | 0.55 | 0.75 | 0.55 | 0.75 | 0.75 | 0.75 | 0.75 | 1.1 | 0.75 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 |
| 040 | 4000 | φ400 | 1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
| 050 | 5000 | φ400 | 2 | 1.1 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 2.2 | 1.5 | 2.2 | 2.2 |
| 060 | 6000 | φ400 | 2 | 1.1 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 2.2 | 1.5 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 |
| 070 | 7000 | φ400 | 2 | 1.5 | 1.5 | 2.2 | 1.5 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 3 |
| 080 | 8000 | φ400 | 2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| 090 | 9000 | φ500 | 2 | 1.5 | 2.2 | 2.2 | 1.5 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 |
| 105 | 10500 | φ500 | 2 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3. |
| 120 | 12000 | φ500 | 2 | 3 | 3 | 3 | 3 | 3 | 4 | 3 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| ModelJDZType | L | w | H | L1 | W1 | H1 | Specification of air supply outlet | Numbers 0f supply 0utlet | Air supply flange[lengthx lengthx air inlet numbers] |
| 010 | 1240 | 860 | 490 | 1290 | 1020 | 540 | φ315 | 1 | 810X440X1 |
| 015 | 1240 | 860 | 490 | 1290 | 1020 | 540 | φ315 | 1 | 810X440X1 |
| 020 | 1240 | 940 | 520 | 1290 | 1100 | 570 | φ315 | 1 | 890X470X1 |
| 025 | 1240 | 940 | 520 | 1290 | 1100 | 570 | φ315 | 1 | 890X470X1 |
| 030 | 1400 | 1060 | 520 | 1450 | 1220 | 570 | φ315 | 1 | 1010X470X1 |
| 040 | 1400 | 1210 | 570 | 1450 | 1370 | 620 | φ400 | 1 | 1060X520X1 |
| 050 | 1400 | 1420 | 570 | 1450 | 1580 | 620 | φ400 | 2 | 1370X520X1 |
| 060 | 1400 | 1640 | 600 | 1450 | 1800 | 650 | φ400 | 2 | 1590X550X1 |
| 070 | 1400 | 1700 | 650 | 1450 | 1860 | 700 | φ400 | 2 | 1650X600X1 |
| 080 | 1400 | 1760 | 670 | 1450 | 1920 | 720 | φ400 | 2 | 1710X620X1 |
| 090 | 1400 | 1800 | 720 | 1450 | 1960 | 770 | φ500 | 2 | 1750X670X1 |
| 105 | 1550 | 2060 | 720 | 1600 | 2220 | 770 | φ500 | 2 | 2010X670X1 |
| 120 | 1550 | 2200 | 800 | 1600 | 2360 | 850 | φ500 | 2 | 2150X750X1 |
JPAC focuses on providing high-quality jet air handling unit and excellent service since 1982. We are a professional jet air handling unit manufacturer and factory of 43000M2 which mainly produce central air conditioning units and dust collector products for around 44 years’ experience. JPAC provides you with jet air handling unit wholesale, customization, design, packaging, industry solutions and OEM & ODM service.
If you have any questions about jet air handling unit, jet air conditioning unit, please don't hesitate to contact us at any time. We will provide detailed information and technical support about central air conditioning units and dust collectors’ features, specifications, solutions and customization options... Welcome you to visit our factory!
