We're professional thin hanging air handling unit manufacturers and suppliers in China, to buy or wholesale ceiling air conditioning unit from our factory. For quotation or if you have any questions, contact us now for customized hanging air conditioning unit and price.
● The inside and outside wall of enclosure panel is color plate and galvanized plate. In the middle is thedesign of high-density polyurethane foam combined with the patented hot break bridge gusset plate structure, which has super high strength and super low air leakage;
● The nylon filter with high efficiency and low resistance has reduced the power consumption, and it is easyto clean, practical and convenient to clean;
● Coiled adopts highly purity seamless copper tube, and hydrophilic aluminum fin;
● The fans used by the unit are selected by professional software, and ensure the optimal operating point;
● There are three kinds of standard outside pressure can be chosen, many different air out way and rownumbers can be selected at the same time. It is convenient and fast for unit selection.
Basic technical parameters of ceiling-mounted air handler | Communications room, right. |
Device model | GDB-3.0 |
Processing air volume (m3/h) | 3000 |
Refrigeration capacity (kW) | 17.5 |
Heating capacity (kW) | 18 |
Unit residual pressure (Pa) | 100 |
quantity | 1 unit |
Unit installation site | indoor |
Summer interior design dry bulb temperature/wet bulb temperature | 27℃/19.5℃ |
Chilled water inlet/outlet temperature | 7℃/12℃ |
Winter interior design dry bulb temperature | 18℃ |
Hot water inlet/outlet temperature | 45℃/40℃ |
power supply | Three-phase four-wire system 380V±10%, 50Hz |
Equipment net weight (kg) | 230 |
Equipment operating weight (kg) | 250 |
Maximum external dimensions of the equipment: W (width)*h (height)*L (length) (mm) | 1075*1075*650 |
Start cabinet/control cabinet overall dimensions (mm) | Customized on demand |
Noise value | 58 |
Main accessories technical parameters | |
Return air plate type coarse filter | |
Plate coarse filter setting position | Return air outlet (external air duct), side extraction cleaning |
Return air outlet size | 975*480 |
Return air inlet wind speed (m/s) | 5 |
Plate type coarse filter | |
Filtration rate | 1.5m/s |
Type | Plate type |
filter material | non-woven fabric |
Filtration efficiency | Counting efficiency 50% (particle size ≥ 2.0μm) |
Surface cooling coil | |
cooling coil manufacturing plant | Jiangping, Jiangsu |
Cooling coil type | Copper tube threaded through aluminum fins |
Heat exchange area | 31m2 |
Number of rows | 4 |
Refrigeration capacity (kW) | 17.5 |
7/12℃ cold water flow (t/h) | 3.6 |
summer inlet air temperature dry bulb/wet bulb | 27/19.5 |
Summer outlet air temperature dry bulb/wet bulb | 16.8/16.3 |
Heating capacity (kW) | 18 |
45/40℃ hot water flow (t/h) | 2.9 |
Winter inlet air temperature Dry bulb/relative humidity | 0 |
Winter outlet air temperature Dry bulb/relative humidity | 15 |
air flow | 3000m3/h |
Wind side resistance (Pa) | 120 |
Water side resistance (kPa) | 45 |
Copper tube specifications | φ16mm |
Aluminum fin thickness/spacing | 0.20/3.0 |
Blower | |
Fan type | centrifugal |
Fan model | 250II |
Fan manufacturer | Zhejiang Yilida |
Number of fans | 1 |
Air volume of a single fan (m3/h) | 3000 |
Fan full pressure | 300 |
External residual pressure | 100 |
Fan speed | 1400rpm |
Fan bearing type | Imported brands |
Motor model | 4P-0.8KW |
Motor manufacturer | Standard configuration |
Motor power | 0.8KW |
Motor speed | 1400rpm |
Transmission mode | Direct connection |
Air outlet direction | Air supply outlet (external air duct) |
Number of air outlets x size | 320*320*1 |
JPAC focuses on providing high-quality thin hanging air handling unit and excellent service since 1982. We are a professional thin hanging air handling unit manufacturer and factory of 43000M2 which mainly produce central air conditioning units and dust collectorproducts for around 44 years’ experience. JPAC provides you with thin hanging air handling unit wholesale, customization, design, packaging, industry solutions and OEM & ODM service.
If you have any questions about thin hanging air handling unit, ceiling air conditioning unit, hanging air conditioning unit, thin air conditioning unit, please don't hesitate to contact us at any time. We will provide detailed information and technical support about central air conditioning units and dust collectors’ features, specifications, solutions and customization options... Welcome you to visit our factory!
